531X166MHCAFG1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Material Handling Coord Card.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 531X166MHCAFG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X166MHCAFG1
  • SKU: 531X166MHCAFG1GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

Product Description

The 531X166MHCAFG1 is a material handling coord. card. The 531X166MHCAFG1 has six small blue potentiometers. These are also known as rheostats or Variable Resistors.  They have a small knob on one side that is used to control about one watt of energy. The 531X166MHCAFG1 has three large capacitors also referred to as condensers that are used to store excess energy for later use in an electrical field that they produce. The 531X166MHCAFG1 has six small red LEDs or light emitting diodes. The 531X166MHCAFG1 contains its instruction manual in two microchips. These microchips are made of a semiconductive material, most of the time it is silicon. Manuals may also refer to microchips as chips, Integrated Circuits or IC for short. The 531X166MHCAFG1 uses fourteen black and silver diodes. These diodes have a small silver line on one side of the diode. The silver line is there to indicate to the engineers which way the energy is moving. The 531X166MHCAFG1 has thirty-one axial-lead resistors. These axial-lead resistors that are used to get rid of unneeded energy. The energy is turned into heat in order to get rid of it. The 531X166MHCAFG1 has six yellow squares that each have this written on top, Aromal 9108A DS2E-M-DC48V-H301, 0.5A 125VAC, 0.5A 110VDC, 2A 30V DC with General Electrics company stamp and USA stamped on the top as well. The 531X166MHCAFG1 has twenty-eight gold tabs along the opposite side of the circuit board from the Variable Resistors.

To acquire more information or a quote please email or call the staff at AX Control.

Repair Services For 531X166MHCAFG1

Type Lead Time Price Action
Repair Service 1-2 weeks $360

Our highly skilled technicians can repair your 531X166MHCAFG1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
