531X135PRGALM2

About the 531X135PRGALM2

The 531X135PRGALM2 is a circuit board produced by General Electric. The 531X135PRGALM2 is known as a Programmer Board and is used in various industrial applications. The 531X135PRGALM2 is available through AX Control but is widely considered an obsolete circuit board. The 531X135PRGALM2 has a crystal oscillator that uses crystals to make a highly precise frequency. The 531X135PRGALM2 has four sets of Jumper Ports. These Jumper Ports come with plastic covers that are used to close or open individual circuits around the board. The 531X135PRGALM2 has a single small black transistor, which can be easily picked out by its three attachment points.

531X135PRGALM2 Device Voltage Limitation

The 531X135PRGALM2 has six Integrated Circuits that hold all the programs for the circuit board to function. The Integrated Circuits are referred to by many names such as a microchip, a chip, or IC for short. They hold data for the 531X135PRGALM2 and only ones referred to as EPROMs can be altered. Some other critical voltage-minded hardware elements in the 531X135PRGALM2's assembly are its:

• eighteen various colored resistors
  • with banding marks
• thirteen capacitors
  • used to store an electric charge
  • one or more pairs of conductors separated by an insulator
• a large LED panel
  • will illuminate with numbers
