531X126SNDAAG1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The GE 531X126SNDAAG1 is a PCB that functions as a snubber board.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 531X126SNDAAG1 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

531X126SNDAAG1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The GE 531X126SNDAAG1 is a PCB that functions as a snubber board.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 531X126SNDAAG1 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The 531X126SNDAAG1 is a replacement board designed by General Electric for use within its drives and exciters.  531x series boards are used in many drives and other control devices created and sold by General Electric.  You should review your system’s user guide or manual to determine whether 531x parts are compatible.

 The 531X126SNDAAG1 functions as a snubber board.  It is a rectangular board that has been factory drilled in each corner to allow for mounting options.  None of these holes are ringed with conductive material.  The board has twelve stab-on connectors located on its surface.  These are located primarily on the lower board edge.  However, one is located in the upper left corner, with four also grouped on the left board edge.   There are twelve additional vertical pin connectors.  These are grouped in two lines of six, with each line bisected by two paper-in-oil capacitors. There are four additional paper-in-oil capacitors on the board, two flanking each end of these connectors.

Other board components include 24 resistors and a single snubber component.  The board is marked with its board id, with the code 006/04, and with its alternate F31X number.

For more information regarding the installation, use, or installation of this equipment, please refer to user guides or manuals originally published and provided by General Electric.  These publications will have important handling information that should be read before any maintenance begins.

AX Control is located in central North Carolina.  If you are local to us, we are happy to work with your personal courier for faster pick up and delivery.

Repair Services For 531X126SNDAAG1

Type Lead Time Price Action
Repair Service 1-2 weeks $408

Our highly skilled technicians can repair your 531X126SNDAAG1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
