5503-336, the Remote XCVR module for Woodwards series of MicroNet VME Racks. This unit receives and sends information via durable copper cable to and from its associated Main XCVR module.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5503-336 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5503-336
  • SKU: 5503336WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5503-336

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
5503-336, the Remote XCVR module for Woodwards series of MicroNet VME Racks. This unit receives and sends information via durable copper cable to and from its associated Main XCVR module.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5503-336 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5503-336
  • SKU: 5503336WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5503-336 Technical Specifications

Cable Interface 2 100 pin metal shell Micro-D connectors
Certifications CSA, CE, and DNV Compliant
Dimensions (in) H 10 3/8 x D 9 3/4 x W 1 1/8
LEDs and Switches None
Operating Temperature Standards -40 - +85 C
Parallel Interface High Speed (VME Transmission Rate)
Series MicroNet Digital Controllers
Slot Occupatied Slot 1

Product Description

Simplex Remote Transceiver Module 5503-336 XCVR sends and receives control data and address information for the associated Main XCVR module. The 5503-336 unit connects to the Main Chassis's VME bus. The chassis decoder determines if this chassis is to be accessed, and if so, it activates 5503-336 XCVR module to receive or send information.

Compared to other units in the MicroNet series, the 5503-336 is rather simple in the fact that it only has two connections in the front for the Main XCVR Chassis and two more at the rear for its own Remote XCVR Chassis.

The Remote XCVR module does not require termination resistors in all expansion chassis except for the last one in the chain. This module must be installed in Slot 1 of your VME Chassis.

Kindly refer to the manuals in the "Manuals" tab above for information regarding this device such as block diagrams and data tables. Additionally, before reaching out to us, please read the same manuals for proper troubleshooting protocols. While the product has been discontinued by Woodward, We at AX Control Inc. will buy, sell, and repair this module. All purchases come standard with a three-year warranty.
