5466-416

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
MicroNet Pentium with Dual Ethernet Option Module 5466-416 can be used with main rack and expansion rack configurations in only simplex system configurations. This unit has an operating limit of up to one-hundred twenty-two degrees Fahrenheit.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-416 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-416
  • SKU: 5466416WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-416

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
MicroNet Pentium with Dual Ethernet Option Module 5466-416 can be used with main rack and expansion rack configurations in only simplex system configurations. This unit has an operating limit of up to one-hundred twenty-two degrees Fahrenheit.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-416 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-416
  • SKU: 5466416WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-416 Technical Specifications

Chassis Expansion with Remote XCVR
Enclosure Type Metal Chassis
Features High-Processing Capability
Manufacturer Woodward Inc, Fort Collins CO
Operating Temperature 32 to 122°F
Redundancy Type Simplex
Weight 22 kg (48 lbs) in Chassis

Product Description

MicroNet Digital Controller module 5466-416 is a Pentium CPU. This specific Pentium CPU is furnished with a Dual Ethernet option that runs the Graphical Application Programming (GAP) within the chosen MicroNet chassis. Please note that when the module has been installed it will be installed in the expansion rack of a simplex system. This module also has a solid-state hard-drive located on the module which uses a standard Windows filing system. The hard drive which has a Windows NT operating system also has an Application program and real-time extensions.

One important thing to note when installing the 5466-416 module is that under no circumstances should you unplug or plug any non-isolated device straight into the CPU while the application is being executed. This CPU does have the capability to be inserted live but monitors, mice, or keyboards should not be unplugged or plugged into the CPU when the GAP application is running.

The 5466-416 module must be configured so a second auto-switching 10-100 Base-TX RJ45 connector can be provided. Sometimes an RS-232 Db9mf filter is needed when being used with some CPUs within the MicroNet system, the Pentium processor does not need this filter.

While using this module the best manual to find information on the Pentium CPU is the 26166 manual, there are three versions of the 26166 manual. Manual 26166V3 provides the most information on the Pentium CPU.

Reviews For 5466-416
Internal Review

The 5466-416 module is an enhanced module as it has Dual Ethernet. The Dual Ethernet module is equipped with a solid-state hard-drive that allows for Windows filing. If you have more questions use the 26166 manuals for more information. - AX Control Tech Team
