5466-411, MicroNet Ethernet RJ45, has four standards, ABS, CSA, CE (EMC), and LRS. This is an Ethernet cable rather than a physical model. The 5466-411 is used to provide communications between main-chassis CPU modules and expansion Chassis Remote RTN modules.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-411 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-411
  • SKU: 5466411WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-411

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
5466-411, MicroNet Ethernet RJ45, has four standards, ABS, CSA, CE (EMC), and LRS. This is an Ethernet cable rather than a physical model. The 5466-411 is used to provide communications between main-chassis CPU modules and expansion Chassis Remote RTN modules.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-411 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-411
  • SKU: 5466411WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-411 Technical Specifications

Features Control Configuration, Data Gathering, Networking of Multiple Controls
Hardware Configuration VME Address #1 or #2 Configuration
Manual 26166V, 26166V2, and 26166V3
Model 10BaseT Ethernet Connector
Power Consumption 15.0 W Max
Product Type MicroNet Ethernet RJ45 Cable
Standards CSA, CE (EMC), ABS and LRS
Voltage 5.0 VDC with 5% Tolerance

Product Description

Model 5466-411 as part of the MicroNet Digital Control Series is a 10BaseT RJ45 Ethernet connector. The model was designed by Woodward Incorporated. There are a number of different features that this connector is used for, some of these features are as follows:

  • Networking of Multiple Controls

  • Data Gathering

  • Control Configuration

The above uses are important for the proper function of the connected MicroNet devices. Along with the previously mentioned functions this module will also be completely relied upon for interfacing IP/TCP Distributed input-output devices within the control system.

When using this connector, the 5466-411 model must also be used with an Ethernet Field Termination Module (FTM) to guarantee robust operation as well as signal integrity of Ethernet devices. Not only does the Ethernet FTM need to be used with double-shield Ethernet candles or SSTPs are required to guarantee that the device will function properly.

The 5466-411 module is also used to help provide communication between the main chassis CPU modules and the expansion chassis remote real-time network modules. This connector allows for input-output data from the expansion chassis to help run the GAP applications in the main chassis CPUs.

This model is difficult to find readily available on the market as it is no longer being actively produced by Woodward but here at AX Control, our sales team can help you find this model. In cases in which the model needs repair, you can contact us for repair pricing at (919) 372-8413 or sales@axcontrol.com.
