5466-318

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
MicroNet Digital Controller 5466-318 is a Triple Modular Redundant Kernel Power Supply module. This module MUST be used/matched with the TMR040 CPU module. The 5466-318 unit can regulate the incoming power supply to 5 VDC or 10 A for the remaining kernel sections.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-318 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-318
  • SKU: 5466318WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-318 Technical Specifications

Chassis MicroNet TMR
CPU TMR040
Features One LED for Power Supply Health
Input Voltage 24 VDC ±10%
Output Current max. 10 A
Output Voltage 5 VDC ±5%
Power Consumption 24 VDC
Standards CE (EMC) and CSA

Product Description

Designed by Woodward Inc for the MicroNet Digital Control Series, the 5466-318 module was designed as a Triple Modular Redundant (TMR) Kernel Power Supply (P.S) module. When this module is installed it will be used in applications that operate on a MicroNet TMR system as one of three kernel power supplies. When installed this module will be inserted into the first slot of the kernel section. Please note that prior to removing a module such as this, all modules within the MicroNet TMR Kernel Power supply must be removed.

The physical makeup of the 5466-318 module is metal and only has one LED on the front faceplate of the module. The LED on the faceplate of the module is used to indicate the Power Health supply of the device. This module will operate on a power supply of twenty-four volts of direct current which comes from the MicroNet main power source. After the power supply has been received from the main MicroNet power source it will regulate it to either 10 A or 5 VDC for the remainder of the kernel section.

When the 5466-318 has been installed it can be used in a number of different sections, these sections are as follows, non-hazardous locations, Class I, Groups A-B-C-D, and Division 2 locations. If the module is installed in locations that are not the above potential errors can occur during operation.

Many models within the MicroNet Digital Control Series are considered obsolete due to no longer being produced by Woodward and not being widely available, the 5466-318 model is not one of these models as it can still be found widely available.

Reviews For 5466-318
Internal Review

The 5466-318 module is a Kernel Power Supply Module and is one of the few modules in the MicroNet series. The module is used for precharge voltage and will send regulated voltages to the remainder of the modules in the kernel section of the MicroNet TMR. - AX Control Tech Team
