Model number 5466-1247 is a CPU TMR5200 unit that is part of the MicroNet Digital Controller series produced by Woodward Inc. This unit is only for the TMR rack. The 5466-1247 module can connect up to three expansion chassis.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-1247 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-1247
  • SKU: 54661247WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-1247

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Model number 5466-1247 is a CPU TMR5200 unit that is part of the MicroNet Digital Controller series produced by Woodward Inc. This unit is only for the TMR rack. The 5466-1247 module can connect up to three expansion chassis.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-1247 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-1247
  • SKU: 54661247WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-1247 Technical Specifications

Chassis MicroNet Triple Modular Redundant (TMR)
CPU TMR5200
Indicators Module Fault and Status
Kernel Power Supply Model Used 5466-1049
Manufacturer Woodward Inc, Fort Collins CO
Operating Temperature -40 to 185°F
Series MicroNet Digital Controllers
Software Version AppManager

Product Description

Woodward MicroNet module 5466-1247 is a TMR5200 CPU that can only be used in Triple Modular Redundant or MicroNet Plus modules as there is not an active CAN on the board. It is vital to note that there are Kernel Power Supply modules that can be used with this unit but they must be matched properly, the Kernel PS model used with this unit is the 5466-1049 module. Some of the features of this unit are the 128 Mbytes of DDR RAM one service port, two CAN ports, one serial port, a Real-Time Network port, and a Real-Time Network clock.

When the 5466-1049 module is installed in the main chassis this unit absolutely cannot be used with just one CPU, multiple CPUs are required for proper operation. The TMR5200 CPU was also designed to be used for 3-2-0 operation. On the front face-plate, there are a number of LEDs, these LEDs are listed as follows:

  • LINK

  • TX/RX

  • CAN #1 and #2

  • WATCHDOG

  • FAULT

  • RUN

  • STANDBY

  • SYSCON

  • IOLOCK

  • LVCC

The above LEDs each have different functions, the description of the FAULT LED is to actively flash red when a fault code is necessary and detected. The LEDs are also grouped together SYSCON, STANDBY, LVCC, IOLOCK, FAULT, and WDOG LEDs are all grouped together, the last four will be red will the top two, the SYSCON will be green and the STANDBY will be yellow.

One key feature of this module is that it can be removed while power is live when being used inserted and removed from the MicroNet Plus or TMR chassis.

Reviews For 5466-1247
Internal Review

If you have limited time and need to remove this unit while power is live it can be done. While the 5466-1247 model can be inserted and removed live it requires to be reset prior to being removed. - AX Control Tech Team
