The 5466-1145 unit produced by Woodward as part of the MicroNet Digital Controller series is a MicroNet Plus CPU5200 model, that is Cyber Security licensed. When operating in redundant mode the 5466-1145 unit will have a second CPU located in the CPU2 section.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-1145 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-1145
  • SKU: 54661145WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-1145

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The 5466-1145 unit produced by Woodward as part of the MicroNet Digital Controller series is a MicroNet Plus CPU5200 model, that is Cyber Security licensed. When operating in redundant mode the 5466-1145 unit will have a second CPU located in the CPU2 section.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-1145 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-1145
  • SKU: 54661145WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control

5466-1145 Technical Specifications

European Compliance EAC Customs Union.
Licensing Type Cyber Security Licensed
Manufacturer Woodward
Regulatory Compliance North American CSA Class 1 Division 2.
Shock US MIL-STD-810C
Technical Manual 26166 (3 Volumes)
Temerpature Range –40 to +85 °C

Product Description

The 5466-1145 unit was designed by Woodward as a MicroNet Plus CPU5200 unit to be used in a redundant or simplex control system. Devices such as this were designed to be used with diesel/gas engine controls, compressor controls, gas/steam turbines, and hydro turbine controllers. The MicroNet Plus devices are VME-based expandable control systems that use simplex or redundant CPU and power supplies that can be used with a variety of input/output model choices. The different types of I/O module choices can be customized to complement the customer's requirements.

The CPU unit on the 5466-1145, CPU5200, is the base CPU model of the MicroNet series and can support redundant CAN and Ethernet communications, optional secure applications, and can also support up to eight chassis for I/O intensive applications. There are two available chassis options that will accommodate different space requirements, either chassis size, which is full-size and narrow, and reserve four slots for the redundant power supplies.

One of the crucial features of the 5466-1145 model is that even if it requires a large amount of I/O, the MicroNet Plus chassis can communicate with up to seven more MicroNet Plus chassis expansions. If needed fiber-optic cables and switches can also be used for communications between the expansion and main chassis if needed.

Reviews For 5466-1145
Internal Review

The 5466-1145 model is the preferred MicroNet Plus Cyber model but unfortunately, this model can be slightly difficult to find. AX Control can do its best to help you find this model, or repair a model you have if needed. - AX Control Technician

Repair Services For 5466-1145

Type Lead Time Price Action
Repair Service 1-2 weeks $4735

Our highly skilled technicians can repair your 5466-1145. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
