The 5466-1115 unit was designed as a High-Density I/O Combo module as part of the MicroNet Digital Controllers series. This unit operates on standard accuracy. Module 5466-1115 was made to be used primarily with use with steam turbine markets and can be used to replace 5466-253 and -316 modules.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 5466-1115 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5466-1115
  • SKU: 54661115WO
  • Manufacturer: Woodward
  • Series: MicroNet Digital Control
