9907-838

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward Load Sharing Module Part 9907-838. This part features PWM/Caterpillar output types and 24 VDC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9907-838 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9907-838

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward Load Sharing Module Part 9907-838. This part features PWM/Caterpillar output types and 24 VDC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9907-838 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9907-838 Technical Specifications

3-Phase PT Inputs 95-130 Vac
Air Quality Pollution Degree 2
Dimensions 273.6 mm X 59.2 mm X 214.1 mm
Manufacturer Woodward
Operation Temp -40 - 158 F
Output to Speed Control +0.5 - +4.5 Vdc analog
Sync Input Compatible with Woodward SPM-A synchronizer

Product Description

 This unit is classified as a part of the Woodward Load Sharing modules and designated with the numerical ID of 9907-838. The 9907-838 LSM model is designed to provide the industrial generator system it is attached to with several functionalities and adjustment capabilities. This unit is outfitted with both isochronous and droop load sharing. The Isochronous load sharing is capable of providing the generator an adjustment of the load it has, even when two or more generators are paralleled to it. The Droop load sharing is able to provide a reduction of output when both no-load and full-load conditions are implemented.

The specified full load condition is from 3 to7 ARms. The 9907-838 unit is outfitted to run on a DC power intake, the voltage ranging between 18 and 32 V/DC, minimum to maximum. The environmental specifications for this unit give it an operational temperature range between -40 to 70 degrees Celsius or -40 to 158 degrees Fahrenheit. It is able to resist a shock that rates up to 40 G, at an 11-millisecond sawtooth pulse.

The 9907-383 is designed with a standard set of dimensions, making it simple to install into an acceptable unit. The length is 10.77 inches, the width is 8.43 inches, and the height is 2.33 inches. The approximate weight for this unit is roughly 3 pounds. It is crucial to install this machine in a humidity-free zone as well as an area that is primarily dust free. Lastly, AX Control INC. is fully equipped to buy, sell, resell, and repair such machines and the like.

Reviews For 9907-838
Internal Review

Works well as it was tested in our wearhouse, so long as it is installed and maintained, as well as operated by a knowing operator. So long as it is used properly and within its intended design. AX Control INC. Tech Team.

Repair Services For 9907-838

Type Lead Time Price Action
Repair Service 1-2 weeks $831

Our highly skilled technicians can repair your 9907-838. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
