Woodward part 8440-3004 EasyGen 1000 Genset Controller. Can be started automatically based on the clock being used in the control, and can close the GCB in manual mode.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8440-3004 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon

3 year warranty





8440-3004

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward part 8440-3004 EasyGen 1000 Genset Controller. Can be started automatically based on the clock being used in the control, and can close the GCB in manual mode.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8440-3004 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8440-3004 Technical Specifications

Burden Current < .15 W
Humidity 95%, non-condensing
Intrinsic Consumption max. 15 W
Max Voltage (400 Vac) 346/600 Vac
Setting Range 50 to 650,000 Vac
Weight approx. 800 g

Product Description

Model 8440-3004 is from the EasyGen 1000 series produced by Woodward INC, this model is available at AX Control INC. We offer repairs and refurbishment to this model as well, if you are interested in repairing your control with us we also offer a one to three-year warranty.

The control mode can start automatically based on the clock that you are using within the control, if you are using the clock in active day mode it will indicate the day of the month, for example, the number 9 would mean the 9th of every month, it will remain on the 9th for the next 24 hours, this mode could allow for the control to start the engine automatically once a month.

When you are using your control the rated voltage or frequency mains of the control differ, the values for the emergency mode of the control will relate to the generator nominal voltage, and the mains do not have any parameters. You can close the GCB of the control while it is in manual mode, to do so make sure that the generator undervoltage monitoring levels one and two must be enabled so the GCB can be closed.

A battery can be connected to the control, make sure that when doing so that the battery plus side of the battery is connected to one side of the relay while the D+ is connected to the other side and specifically the current limiting resistor, make sure that the current limiting resistor is connected with the correct application, if it is 24 V then it should be 210-240 Ohm.

  • EasyGen-1600
Reviews For 8440-3004
Internal Review

This control comes with the capability to remotely start if the clock used within the control is set up in active day mode which would potentially start the control automatically on the day specifically indicated. Read the manual thoroughly to ensure that everything has been set up correctly. - AX Control Tech Team

Repair Services For 8440-3004

Type Lead Time Price Action
Repair Service 1-2 weeks $2126

Our highly skilled technicians can repair your 8440-3004. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
