Woodward part 8440-2253 EasyGen 1000 Genset Controller. Also known as EasyGen-1600, equipped with a USB service and an RS485 port, Ohm reading of 0-500.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8440-2253 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon

3 year warranty





8440-2253

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
Woodward part 8440-2253 EasyGen 1000 Genset Controller. Also known as EasyGen-1600, equipped with a USB service and an RS485 port, Ohm reading of 0-500.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8440-2253 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8440-2253 Technical Specifications

Accuracy Class 1
Alternator Windings 3p-3w, 3p-4w, 1p-2w, 1p-3w
Dimensions 219×171×61 mm
Housing Connection screw/plug terminals 2.5 mm²
Marine Approvals GL and LR
Power Supply 6.5-40.0 Vdc

Product Description

The control model 8440-2253 made by Woodward INC is from the EasyGen 1000 series, this series is available at AX Control inc, we can also repair and refurbish your control which we offer a one to three-year warranty to protect your control after it had been repaired. The 8440-2253 model is known as a Genset controller. It also has an alternate part number known as EasyGen-1600, as its alternate part number control model 8440-2253 means that other available connections include a speed input, J1939 for engine ECU, a USB service port, and an RS485 port for the model.

For the temperature input of the control, the resistance should be between zero and five-hundred Ohm, if the temperature input has a value of sixteen and five hundred and twelve the resistance should read as eighty Ohm.

When the emergency mode on the control is terminated and terminal six of the control has been switched off the GCB setting of the control will open and then it will begin to cool down. To be sure that you don’t have an occurrence of a black busbar and to meet NFPA requirements make sure that the default settings within the control are set to start in automatic mode.

Note that when operating your control that it under absolutely no circumstances can your EasyGen model measure the voltage of the auxiliary alternator that will occur at the relay output.

If you are interested in purchasing this control or even have a surplus that you wish to sell you can contact our sales department by phone or email.

  • EasyGen-1600
Reviews For 8440-2253
Internal Review

This control comes with five discrete inputs which include but is not limited to J1939 for engine ECU and an RS485 port. Please consult the attached manual as well as a certified professional before you start your control. - AX Control Tech Team

Repair Services For 8440-2253

Type Lead Time Price Action
Repair Service 1-2 weeks $2423

Our highly skilled technicians can repair your 8440-2253. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

8440-2253 Manuals, White Papers, Data Sheets, and Troubleshooting
