GEM42100

Q: What is the range for the GEM42100 Presettable Counter&#39;s presets?

The GEM42100 counter&#39;s preset range is quite wide at 0 to &plusmn;999999.

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The GEM42100 6-Digit Presettable Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GEM42100 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GEM42100
SKU: RL-59451

Manufacturer: Red Lion
Series: GEMINI 1000/2000 Counters and Indicators

Description
Repairs
Warranty
Manuals

GEM42100 Technical Specifications

Part Number	GEM42100
Functional Description	6-Digit Presettable Counter/Indicator
Series	GEMINI 1000/2000 Counters and Indicators
Manufacturer	Red Lion
Functionality	Counter or Rate Indicator
AC Power	115/230 VAC (±10%), 50/60 Hz, 20 VA
DC Power	11 to 14 VDC @ 0.7 A max
Scale Factor Range	0.0000 to ±5.9999
Output Time Delay Range	0.01 to 599.99 seconds
Relay Life	100,000 cycles at max. rating
Installation Category	II
Pollution Degree	2

About the GEM42100

The GEM42100 6-Digit Presettable Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series comes with a series of standard hardware elements seen in most models, such as its:

6 Digit-Based Pushbuttons
3 Other Pushbuttons
LED-Backlit Display
NEMA-Rated Front Interface
DIP Switches
Terminal Strips

Each of the terminal strips in the GEM42100 6-Digit Presettable Counter/Indicator's assembly is accompanied by a printed wiring diagram. One of the GEM42100 6-Digit Presettable Counter/Indicator's 3 other pushbuttons is dedicated to a reset function.

GEM42100 Output Termination Modes

The GEM42100 comes with a series of output termination modes available, including:

Terminate at “other” Output Start (Gemini 2000 only) Mode
Terminate at “other” Output End (Gemini 2000 only) Mode
Terminate at Manual Reset Mode
Terminate at Manual Reset End Mode
Terminate after Time Delay Boundary Mode

Reviews For GEM42100

Internal Review

(5.0)

The lead zero blanking for this model begins with the second digit to the left of the decimal point. This GEM42100 Presettable Counter also has the capacity to store up to three "dummy zeros" from the right of the backlit numeric display. The GEM42100 offers 5-digit input scaling, and can be repaired. - AX Control Lead Technician
