About the GEM42060
The GEM42060 6-Digit Counter Module here was originally manufactured for Red Lion's GEM1000 or GEM2000 Series, and displays a number of standard series-wide hardware elements, such as its:
- 6 digit pushbuttons
- 3 other diagnostic pushbuttons
- NEMA-rated protective display
- Terminal strips
- Terminal connection diagrams
- LED-backlit display window
The display central to the diagnostics of the GEM42060 6-Digit Counter Module is numeric in nature and cannot display any symbols or sophisticated diagrams. The front interface of the unit has a NEMA 4 rating with IP65 protection.
GEM42060 Electrical Specifications
A number of important electromagnetic compatibility ratings exist for this module, including the counter's:
- Electrostatic discharge EN 61000-4-2 Level 2; 4 Kv contact 1 Level 3; 8 Kv air
- Electromagnetic RF fields EN 61000-4-3 Level 3; 10 V/m 80 MHz - 1 GHz
- Fast transients (burst) EN 61000-4-4 Level 4; 2 Kv I/O 2 Kv power 2
- RF conducted interference EN 61000-4-6 Level 3; 10 V/rms 150 KHz - 80 MHz
- Power frequency magnetic fields EN 61000-4-8 Level 4; 30 A/m
