GEM41100 Image One
3 year warranty

❯

GEM41100 Image 1
GEM41100 Image 2
GEM41100 Image 3
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

GEM41100

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The GEM41100 6-Digit Presettable Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a GEM41100 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GEM41100
  • SKU: RL-59455
  • Manufacturer: Red Lion
  • Series: GEMINI 1000/2000 Counters and Indicators

GEM41100 Technical Specifications

Part Number GEM41100
Functional Description 6-Digit Presettable Counter/Indicator
Series GEMINI 1000/2000 Counters and Indicators
Manufacturer Red Lion
Self-Test Non-Destructive
Frequency Doubling Both edges of input signal
Output Delay 0.01 to 599.99 seconds
Memory Non-volatile E2PROM
Programmable Outputs Time Range 0.01 to 599.99 seconds
Enclosure Class A
NEMA Rating 4
IP Code 65

About the GEM41100

The GEM41100 6-Digit Presettable Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series has two possible reset actions that it can take. These would have to include its:

  • Reset-to-Zero Action
  • Reset-to-Preset Action

Reset-to-Zero Action activates an output when the count equals the preset value. When reset, this counter turns to zero. With Reset-to-Preset, the output activates when the count equals zero, and the counter returns to preset value when it is reset.

GEM41100 6-Digit Presettable Counter/Indicator Reset Modes

In addition to two possible reset actions, the GEM41100 6-Digit Presettable Counter/Indicator retains a number of additional reset modes, including its:

  • Manual Reset Mode
  • Automatic Reset at Preset Mode
  • Automatic Reset after Output Time Delay Mode

A manual reset of the GEM41100 6-Digit Presettable Counter/Indicator can be both triggered remotely and by the pressing of a pushbutton on the unit's front interface.

Frequently Asked Questions about GEM41100

How many front panel lockout modes does this GEM41100 Counter have?

This GEM41100 6-Digit module has four total lockout modes, with resets able to be enabled or disabled during any one of them.

Where are the GEM41100 6-Digit Presettable Counter/Indicator's relays mounted?

The relays present in the GEM41100 6-Digit Counter's assembly are mounted on a printed circuit board deemed as field-replaceable.

Reviews For GEM41100

Internal Review
(5.0)

Front panel lock-out modes for this unit specifically include Complete Front Panel Disable, Preset(s) Enabled Only, Scale Factor Enabled Only, and Both Preset(s) and Scale Factor Enabled. For diagnostic purposes, up to three right-hand dummy zeros can be stored in its backlit numeric display. Both 2-Input Anti-Coincidence Add AND 2-Input Anti-Coincidence Add/Subtract are available counting modes for the GEM41100. - AX Control Lead Technician
