GEM33060

Q: Are the GEM33060 unit&#39;s operating and storage humidities different?

No. 85% max. relative humidity (noncondensing) from 0 to 50&deg;C is the GEM33060 Digital Counter&#39;s humidity for both storage and operation.

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The GEM33060 Counter/Rate Indicator made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GEM33060 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GEM33060
SKU: RL-59477

Manufacturer: Red Lion
Series: GEMINI 1000/2000 Counters and Indicators

Description
Repairs
Warranty
Manuals

GEM33060 Technical Specifications

Part Number	GEM33060
Functional Description	Counter/Rate Indicator
Manufacturer	Red Lion
Series	GEMINI 1000/2000 Counters and Indicators
Magnetic Pickup Input Sensitivity	150 mV peak nominal
Magnetic Pickup Input Hysteresis	100 mV nominal
Magnetic Pickup Input Impedance	26.5 KΩ @ 60 Hz nominal
Magnetic Pickup Input Max Voltage	±50 V peak
Safety Requirements	IEC 1010-1, EN 61010-1
Sample Time Multiplier	1, 2, 5, 10, 20, or 50x
Scale Multiplier	1, 0.1, 0.01, or 0.001x

About the GEM33060

The GEM33060 Counter/Rate Indicator made for Red Lion's GEMINI 1000/2000 Series has numerous different reset modes. These include its:

Manual Reset Mode
Automatic Reset at Preset Mode
Automatic Reset after Output Time Delay Mode

In addition to these modes, this counter unit also offers two separate reset actions:

Reset-to-Preset
Reset-to-Zero

GEM33060 Electromagnetic Compatibility

Electromagnetic Compatibility ratings for this GEM33060 presettable counter include:

Electrostatic discharge EN 61000-4-2 Level 2; 4 Kv contact 1 Level 3; 8 Kv air
Electromagnetic RF fields EN 61000-4-3 Level 3; 10 V/m 80 MHz - 1 GHz
Fast transients (burst) EN 61000-4-4 Level 4; 2 Kv I/O 2 Kv power 2
RF conducted interference EN 61000-4-6 Level 3; 10 V/rms 150 KHz - 80 MHz

Frequently Asked Questions about GEM33060

Are the GEM33060 unit's operating and storage humidities different?

No. 85% max. relative humidity (noncondensing) from 0 to 50°C is the GEM33060 Digital Counter's humidity for both storage and operation.

How are the GEM33060 Counter's Preset and Scale Factor functions initialized?

Two pushbuttons exist on the front face of the GEM33060 to kick off Preset and Scale Factor functions.

Reviews For GEM33060

Internal Review

(5.0)

Lo Bias has Input trigger levels VIL of 1.5 V max with a VIH = 3.75 V, while its Hi Bias has Input trigger levels VIL of5.5 V max with a VIH of 7.5 V. It has durable relays with life expectancies of 100,000 cycles. While this may be true, these same relays are not immediately accessible for maintenance as they are base PCB-mounted. This PCB is field-replaceable, though. - AX Control Lead Technician
