The GEM33001 Dual Rate Indicator Module made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GEM33001 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GEM33001
SKU: RL-59471

Manufacturer: Red Lion
Series: GEMINI 1000/2000 Counters and Indicators

Description
Repairs
Warranty
Manuals

GEM33001 Technical Specifications

Part Number	GEM33001
Functional Description	Dual Rate Indicator Module
Series	GEMINI 1000/2000 Counters and Indicators
Manufacturer	Red Lion
Preset Range	0 to ±999999
Scaling	5-digit input
Scale Factors Range	0.0000 to ±5.9999
Operating Temperature	0 to 50°C
Storage Temperature	-40 to 80°C
Altitude	Up to 2000 meters
NEMA Rating	4
IP Rating	65

About the GEM33001

The GEM33001 Dual Rate Indicator Module made for Red Lion's GEMINI 1000/2000 Series comes with a number of basic hardware elements, such as its:

LED backlight
DIP switches
Terminal strips
Terminal strip wiring diagrams
Factory-printed sticker labels
Interior 100,000-cycle relays
Diagnostic pushbuttons

To be specific, the GEM33001 Indicator's relays are mounted upon the unit's interior or base printed circuit board.

GEM33001 Counting

A number of different modes are available to customize the GEM33001's counting process. These include the:

Count with Up/Down Control Mode
2-Input Anti-Coincidence Add and Add/Subtract Modes
Quadrature and Quadrature X4 Modes

The GEM33001 also supports two total reset actions and numerous different reset modes available in original documentation.

Frequently Asked Questions about GEM33001

How many digits does the GEM33001 Indicator's internal counter have?

The GEM33001 unit has a nine-digit internal counter, which has its own customizable multiplier as well.

What reset modes are accessed by the GEM33001 Indicator Module?

The GEM33001 Indicator utilizes reset modes including Manual Reset, Automatic Reset at Preset, and finally Automatic Reset after Output Time Delay.

Reviews For GEM33001

Internal Review

(5.0)

This GEM33001 Counter has different maximum count rates depending on the unilateral or bilateral nature of its selected mode. Please keep in mind also that the GEM33001's two most relevant functions in Scale Factor and Preset are accessed via diagnostic pushbuttons and not the 33001's display window. This GEM33001 Counter Module can multiply its base sample time by factors of 1, 2, 5, 10, 20, or even 50. - AX Control Lead Technician
