Home Red Lion GEMINI 1000/2000 Counters and Indicators GEM33

❮

❯

About | Product Specifications | FAQs

GEM33

Q: How can manual resets of the GEM33 Digital Counter be triggered?

This GEM33 Module&#39;s manual resets can be triggered via remote RST or the aforementioned front pushbutton.

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The GEM33 Presettable Counter Module made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GEM33 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GEM33
SKU: RL-59475

Manufacturer: Red Lion
Series: GEMINI 1000/2000 Counters and Indicators

Description
Repairs
Warranty
Manuals

GEM33 Technical Specifications

Part Number	GEM33
Functional Description	Presettable Counter Module
Series	GEMINI 1000/2000 Counters and Indicators
Manufacturer	Red Lion
Scaling	5-digit input
Scale Factor Range	0.0000 to ±5.9999
Scale Multipliers	1, 0.1, 0.01, or 0.001
Right-Hand Dummy Zeros	Up to 3
Hi Bias	Input trigger levels VIL = 1.5 V max., VIH = 3.75 V
Lo Bias	Input trigger levels VIL = 5.5 V max., VIH = 7.5 V
Safety Requirements	IEC 1010-1, EN 61010-1

About the GEM33

The GEM33 Presettable Counter Module made for Red Lion's GEMINI 1000/2000 Series comes with a series of standard hardware components, including the module's:

Numeric display window
LED backlighting
NEMA 4-rated front interface
DIP switches
Terminal strips
Terminal wiring diagrams
Diagnostic and numeric pushbuttons

The GEM33 Presettable Counter Module comes with 6 numeric buttons and 3 diagnostic buttons, including the all-important manual reset pushbutton.

GEM33 Reset Modes

Available reset modes for the GEM33 Module here are:

Manual Reset
Automatic Reset at Preset
Automatic Reset after Output Time Delay

This GEM33 Digital Counter also has both reset-to-zero and reset-to-preset reset actions equipped.

Reviews For GEM33

Internal Review

(5.0)

The GEM33 digital counter here has an output time delay programmable from 0.01 to 599.99 seconds. It also has 100,000 cycles at max. rating relays life expectancy. These relays should be directly installed onto the counter unit's interior circuitry or base PCB. - AX Control Lead Technician
