GEM30100

About the GEM30100

The GEM30100 6-Digit Counter Module made for Red Lion's GEM1000/2000 Counters and Indicators Series has a recognizable design shared by almost all of the units within this series. For instance, it makes use of an LED-based red numeric display window. Some other hardware traits of the GEM30100 Counter are its:

• DIP switch collection
• Internal circuit-based relays
• Printed terminal connection guide
• Terminal blocks with terminal points
• NEMA-rated front chassis

To be specific, the NEMA rating of the GEM30100's front interface sits at a hearty 4. It also retains an IP65 rating for the same interface.

GEM30100 Electromagnetism

The GEM30100 has a lot of specific electromagnetic ratings important to its function. Some of these include the unit's:

• Electrostatic discharge EN 61000-4-2: Level 2 4 Kv contact 1 Level 3 8 Kv air
• Electromagnetic RF fields EN 61000-4-3:  Level 3 10 V/m 80 MHz - 1 GHz
• Fast transients EN 61000-4-4: Level 4 2 Kv I/O 2 Kv power squared
• RF conducted interference EN 61000-4-6: Level 3 10 V/rms 150 KHz - 80 MHz EN 61000-4-8 Level 4 30 A/m
