The GEM10061 6-Digit Digital Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a GEM10061 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GEM10061
  • SKU: RL-59458
  • Manufacturer: Red Lion
  • Series: GEMINI 1000/2000 Counters and Indicators

GEM10061 Technical Specifications

Part Number GEM10061
Functional Description 6-Digit Digital Counter/Indicator
Series GEMINI 1000/2000 Counters and Indicators
Manufacturer Red Lion
Reset Actions Reset-to-Zero, Reset-to-Preset
Preset Range 0 to ±999999
Frequency Doubling Both edges of input signal
Sample Time Multiplier 1, 2, 5, 10, 20, or 50x
Operating Temperature 0 to 50°C
Storage Temperature -40 to 80°C
Humidity 85% max. relative humidity - 0 to 50°C

About the GEM10061

The GEM10061 6-Digit Digital Counter/Indicator made for Red Lion's GEMINI 1000/2000 Series has a number of counting modes that it relies on. These include this GEMINI 1000 Series unit's:

  • Count with Inhibit Mode
  • Count with Up/Down Control Mode
  • 2-Input Anti-Coincidence Add and 2-Input Anti-Coincidence Add/Subtract Modes
  • Quadrature and Quadrature X4 Modes

GEM10061 Output Termination

Similarly to its counting, this GEM10061 Counter can be pre-set to a number of output termination modes for ease of use. Some of these are its:

  • Terminate at “other” Output Start (Gemini 2000 only) Mode
  • Terminate at “other” Output End (Gemini 2000 only) Mode
  • Terminate at Manual Reset Mode
  • Terminate at Manual Reset End Mode
  • Terminate after Time Delay Mode
  • Boundary Mode

This is the full list of GEM10061 output termination modes. The first two listed above here do not apply to this GEM10061 unit as it is a GEMINI 1000 model.

Frequently Asked Questions about GEM10061

Is the GEM10061's output time delay programmable?

Yes. The actual length of the GEM10061 Counter's output delay can be selected from a range between  0.01 to 599.99 seconds.

What does a dual unit personality mean for the GEM10061?

This GEM10061's dual unit personality just refers to the fact that it can act as both a Counter and a Rate Indicator.

Reviews For GEM10061

Internal Review
(5.0)

The self-test for this GEM10061 Counter Unit tests for basic components such as its display, output circuitry, and central processing unit. While it does have six digit-based pushbuttons, it offers three more for other various diagnostic entries. One such button is the GEM10061's manual reset button, which can be used in lieu of traditional remote resetters. - AX Contol Lead Technician
