GEM10001

Q: What are the most commonly-used functions of the GEM10001 Module?

This GEM10001 Counter Module&#39;s most common functions include Preset and Scale Factor.

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The GEM10001 Digital Counter Module made for Red Lion's GEMINI 1000/2000 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GEM10001 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GEM10001
SKU: RL-59452

Manufacturer: Red Lion
Series: GEMINI 1000/2000 Counters and Indicators

Description
Repairs
Warranty
Manuals

GEM10001 Technical Specifications

Part Number	GEM10001
Functional Description	Digital Counter Module
Series	GEMINI 1000/2000 Counters and Indicators
Manufacturer	Red Lion
Magnetic Pickup Input Sensitivity	150 mV peak nominal
Magnetic Pickup Input Hysteresis	100 mV nominal
Magnetic Pickup Input Impedance	6.5 KΩ @ 60 Hz nominal
Magnetic Pickup Input Max Voltage	±50 V peak
Lo Bias	Input trigger levels VIL = 1.5 V max., VIH = 3.75 V
Hi Bias	Input trigger levels VIL = 5.5 V max., VIH = 7.5 V

About the GEM10001

The GEM10001 Digital Counter Module made for Red Lion's GEMINI 1000/2000 Series has a number of reset modes that it can access in the event of a potentially-fatal functional fault, such as its:

Manual Reset
Automatic Reset at Preset
Automatic Reset after Output Time Delay

The GEM10001 Digital Counter Module's manual reset can either be triggered remotely or via one of the pushbuttons on the module's NEMA 4-rated front interface.

GEM10001 Digital Counting Modes

Some of the specific counting modes that the GEM10001 Digital Counter Module is able to perform include its:

Count with Inhibit Mode
Count with Up/Down Control Mode
2-Input Anti-Coincidence Add Mode
2-Input Anti-Coincidence Mode
Add/Subtract Mode
Quadrature Mode
Quadrature X4

Reviews For GEM10001

Internal Review

(5.0)

The GEM10001 Unit has several reset options, as well as the capability to perform a full front interface lock-out if faced with a potentially fatal fault. Some specific lock-out modes for this device are: Complete Front Panel Disable, Preset(s) Enabled Only, Scale Factor Enabled Only, and Both Preset(s) and Scale Factor Enabled modes. - AX Control Lead Technician
