G310C230

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
The G310C230 model from Red Lion is equipped with dual Ethernet capabilities and isolated communication ports. This model also has a USB host. The backlight of this model is an LED and will have a typical lifetime of 70,000 hours when at room temperature.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a G310C230 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G310C230
  • SKU: G310C230RL
  • Manufacturer: Red Lion
  • Series: G3 Series HMIs

G310C230 Technical Specifications

Part Number G310C230
Series G3 Series HMIs
Manufacturer Red Lion
Description 10" TFT Analog Touchscreen Terminal
Brightness 450 Candelas per Square Meter
Features Dual Ethernet, USB Host, and Isolated Comms
Dimensions H 9.50" x W 12.83" x D 2.45"
Construction Steel Rear Metal Enclosure w/ NEMA 44X/IP66 Aluminum Front Plate
Power Supply Voltage +24 VDC ±20%
Keypad Programmable 8-key membrane
Typical Battery Lifetime 10 Years
PGM Port RS232 Port via RJ12
Mounting Stud Torque Max. 17 Inch-Pounds
Mounting Requirements Max Panel Thickness of 0.25"
UL Hazardous File #E245515

Product Description

The G310C230 model is the second of the G310C2 models from Red Lion. The model has the same screen size, which is a 10.4" TFT VGA display. This specific model can only be used in indoor applications and is equipped with isolated communication ports, a USB host, and dual Ethernet communications. The associated display for this model is a ten-point four-inch TFT or VGA display operator interface. The resolution of this model is approximately six hundred and forty by four hundred and eighty pixels. The backlight on the G310C230 terminal is a LED backlight with an approximate lifetime of seventy thousand hours when used at room temperature and full brightness. The brightness of this model can be adjusted to help extend its lifetime.

An optional expansion card can be installed on the G310C230 model; to do so, all power and input-output communications must be disconnected, and the rear cover of the model must also be removed. Connect the associated cable on the expansion card to the connector on the main board of the operator interface terminal. Once this has been completed, the rear cover can be replaced, and the model can be powered up again; please ensure no errors are occurring once the terminal has been powered back on.

The software type on the G310C230 model is Crimson software which requires a version of 2.0 or later. The Crimson software used is user-friendly and free of charge compared to other manufacturers, who charge for the software needed to configure their devices.

Frequently Asked Questions about G310C230

Are there any downsides to the G310C230 model?

Yes, one of the main downsides of the G310C230 operator interface terminal is that the number of keys on the device is limited. Typically the smaller the model, the more keys the operator interface terminal will have; therefore if you want a panel with more programmable keys, a smaller model is recommended. While there are not that many keys, seven of the eight keys are programmable, meaning that the user can program the keys to their preference.

What are the main screen icons on the G310C230 operator interface terminal when using the Crimson software, and how do they function?

The main screen icons used with the Crimson software and the G310C230 panel are the web server, security manager, programming, user interface, data logging, communications, and data tags. When using the communications icon with the G310C230 terminal and Crimson software, the icon allows for one or more potentially connected devices to be accessed using the master protocols; using the slave protocols on the icon, data items can be configured to write or read the items.

Reviews For G310C230

Internal Review
(5.0)

There is another G310C2 model. This panel is superior to the previous model due to the added feature of dual ethernet. The G310C230 terminal also accepts several option cards, which are a DeviceNet communication card, GSM/GPRS option card, a Profibus DP communication card, a CANOpen communication card, and an RS232/485 option card. When the G310C230 terminal uses the DeviceNet option card it adds an enhanced capability to communicate with any DeviceNet Master. - AX Control Tech

  • G310C2

Repair Services For G310C230

Type Lead Time Price Action
Repair Service 1-2 weeks $1144

Our highly skilled technicians can repair your G310C230. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
