8030-PS-70

Name: 8030-PS-70
Brand: Square D
SKU: SD-1784
Price: 364 USD
Availability: LimitedAvailability
Rating: 4.8 (8 reviews)

4.75 (8)
Click a star to rate this product

4.75 (8)
Click a star to rate this product

8030-PS-70 Square-D PLC Power Supply. SY/MAX 8030, 120 Input/Output Capacity Unit, 24VDC Input.

Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8030-PS-70 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8030-PS-70
SKU: SD-1784

Manufacturer: Square D
Series: Symax Class 8030

Description
Repairs
Warranty
Manuals

8030-PS-70 Technical Specifications

Manufacturer	Square D
Series	Symax Class 8030
Part Number	8030-PS-70
Power	24VDC
Shipping Weight	8.18 lb

About the 8030-PS-70

Model Number: 8030-PS-70.
Original Manufacturer: Square D.
Product Family: SY/MAX 8030 Class.
Function: Power supply module.
Input Power: 24VDC.
I/O Capacity: 120 Input/Output.
Availability: Discontinued by Square D; available from AX Control in refurbished or potentially new condition.

Physical Description

Form Factor: Large, rectangular black housing with many holes on its sides.
Front Panel Markings:
- "POWER SUPPLY 24 VDC 80 WATTS."
- Small, rectangular yellow piece with two thick red wires attached.
- Black diamond shape with white text "GROUND" in the center.
- Plus sign above and minus sign below the diamond.
- "BATTERY LOW" indicator light.
- Manufacturer's label with module information.
- "CAUTION: REMOVE PLUG BEFORE REMOVING BATTERY TRAY" warning text at the bottom.

Weight

Weight (without packaging): Approximately 8.18 lbs. (3.71 kg).

Reviews For 8030-PS-70

Internal Review

(5.0)

The Square D 8030-PS-70 is a 24VDC input power supply module designed for the SY/MAX 8030 Class product family, providing a 120 Input/Output capacity. While no longer manufactured by Square D, it remains available through secondary markets, often in refurbished or new surplus condition. Functional Design and Safety Features – This robust, rectangular black unit is clearly labeled on its front, indicating its 24VDC, 80-watt power supply capability. Key features include a ground indicator, a "BATTERY LOW" light for operational feedback, and a critical "CAUTION: REMOVE PLUG BEFORE REMOVING BATTERY TRAY" safety warning. Weighing approximately 8.18 lbs (3.71 kg), its sturdy construction with ventilation holes suggests a design focused on durability and proper thermal management for industrial environments. The 8030-PS-70 remains a functional component for maintaining legacy SY/MAX systems. – AX Control Technician
