8030-HIM-191A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.57 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.57 (7)
  • Click a star to rate this product
8 Point Input Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 8030-HIM-191A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8030-HIM-191A
  • SKU: 8030HIM191ASD
  • Manufacturer: Square D
  • Series: Symax Class 8030

About the 8030-HIM-191A

The 8030-HIM-191A, part of the SY/MAX Class 8030, is an 8 Point Input Module.

When inserted into a rack, the 8030-HIM-191A can be used as a diagnostic aid for testing and troubleshooting the inputs of the programmable controller system. The module does not require any external writing, so therefore a terminal block is not included with the module.

The 8030-HIM-191A module features eight inputs, 40mA of current draw on SY/MAX power supply, an ambient temperature rating of 0 - 60 degrees Celsius, and a humidity rating of 0 - 95% non-condensing. The 8030-HIM-191A module may also be sued in the following I/O rack assemblies: 8030-HRK-100 and 8030-HRK-200.

The input simulator module may be used in the rack assembly as a toggle switch to select different functions or sequences in the control program. Depending on the size and routing of wires to the terminals of any adjacent modules, it may be necessary to remove the adjacent terminal block before removing the 8030-HIM-191A module.

To install the 8030-HIM-191A, insert the module into the rack (while holding the module’s pull tab in a horizontal position as the module is inserted) and tighten the captive screw at the bottom of the module. After that lower the latching clamp to properly secure the top of the 8030-HIM-191A module.

The 8030-HIM-191A module weighs approximately 1.0 lbs., without any of AX Control’s packaging, and is rectangular in shape.

AX Control is based in Fuquay-Varina, North Carolina, but we ship to any country around the world that is not under US embargo. We ship using UPS, FedEx, DHL, or TNT. We are happy to quote shipping costs to your location upon request. We even offer blind shipping as an option.

We accept Visa, MasterCard, Discover, American Express, and Personal Checks for all North American purchases. For international orders, we accept payment with wire transfers. Additionally, if you happen to be in the Fuquay-Varina, North Carolina area, cash can always be used for local pickups for your convenience.

Repair Services For 8030-HIM-191A

Type Lead Time Price Action
Repair Service 1-2 weeks $324

Our highly skilled technicians can repair your 8030-HIM-191A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

8030-HIM-191A Manuals, White Papers, Data Sheets, and Troubleshooting
