In Stock! Power Supply Slot Panel Mount. Call Now! | Image
3 year warranty

In Stock! Power Supply Slot Panel Mount. Call Now! | Image
In Stock! Power Supply Slot Panel Mount. Call Now! - Wiring Diagram Image

8030-ADP-100

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.77 (13)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.77 (13)
  • Click a star to rate this product
SY/MAX Power Supply Slot Panel Mount

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 8030-ADP-100 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8030-ADP-100
  • SKU: 8030ADP100SD
  • Manufacturer: Square D
  • Series: Symax Class 8030

Product Description

The 8030-ADP-100 module was designed and manufactured by Square D as part of the SY/MAX 8030 series of processor and related products. The 8030-ADP-100 module is classified as a Bracket for the Slot Mount 8030-PS-25. Be advised that the 8030-ADP-100 module requires the 8030-CC-15 cable for proper operation. Please follow the links above to find the 8030-PS0-25 power supply and the 8030-CC-15 cable on AX Control’s website. The 8030-ADP-100 module has since been discontinued by Square D, the designated OEM, but AX Control may have this product in either reconditioned form or in brand new form from surplus stock. Please call or email AX Control to learn more about whether or not this product is available to purchase today.

With the 8030-ADP-100 power supply slot panel mount, the power supply it is connected to will have the dimensions 13.04 x 6.08 x 1.61. The 8030-PS-25, which is the power supply that the 8030-ADP-100 is designed to be compatible with, is a power supply for a 128 I/O with 120/240 VAC of power incoming. The cable that is required for use with the power supply and the panel mount, the 8030-CC-15 cable, has a total length of 21 inches and is a P1 connector.

The 8030-ADP-100 panel mount has an approximate weight of 1.80 lbs. or 0.82 kg. This approximate weight total does not include any of AX Control’s safe, reliable packaging materials, which are specially designed to ensure that your product arrives to your facility without any damage whatsoever.
