Square D Sy/max Class 8005 DN-216 Input 24VDC.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 8005-DN-216 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8005-DN-216

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Square D Sy/max Class 8005 DN-216 Input 24VDC.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 8005-DN-216 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8005-DN-216 Technical Specifications

Manufacturer Square D
MPN 8005-DN-216
Series SY/MAX Class 8005
Type Input Module

Product Description

The 8005-DN-216 is a DC Input Module created by Square-D. It is no longer being suopported by this company and may be tough to find. AX Control, however, still tries to retain it in stock.

The 8005-DN-216 is a 16 Function 24 VDC Source Input Module. It has an isolation method that uses a photocoupler and a top internal current draw of 40mA. It has an input voltage that ranges between 10-30 VDCs. It has 16 input points with an 8-point per common connection. It can maintain a 7 milliseconds turn on time and a 10 VDC turn on voltage. It has an 11 millisecond turn off time and a turn off voltage of 3 VDCs. It has a 2.3 k-ohms input impedance. This unit weighs roughly 170 grams.

Overall, there is a total of 16 LED lights on the 8005-DN-216. These indicators have corresponding terminal screws that they are monitoring. The LEDs will glow red when there are wires attached to its terminal. There are two terminals labeled NC that should not have anything attached to them. There are also two terminals labeled COM (+) that are not typically internally connected. The terminal screws on this device are the M3.5 type.

The 8005-DN-216 can be attached to a processor unit, expansion base, or expansion power supply unit. Two of the 8005-DN-216 modules can be attached to one of these bases. The entire set-up is then mounted vertically to either a wall or panel. Never mount this system horizontally.

Frequently Asked Questions about 8005-DN-216

How many input points is the 8005-DN-216 equipped with?
The 8005-DN-216 is a input module with 16 input points that can be used with other devices in the SY/MAX Class 8005 series.
What is the VDC rating on the 8005-DN-216?
The 8005-DN-216 is a 24VDC function input module.
Can AX Control repair my 8005-DN-216?
AX Control can preform board level repairs on any of your devices, including the 8005-DN-216. When the repairs are complete AX Control technicians will run the fully function test to ensure your 8005-DN-216 is fully repaired.
