Reliance Electric AC Mains Filter for 1SU41007/1SU41010

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 2DF4284 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 2DF4284
  • SKU: 2DF4284RE
  • Manufacturer: Reliance Electric
  • Series: SP500 AC Drives

2DF4284 Technical Specifications

Manufacturer Reliance Electric
Series SP500
Part Number 2DF4284
HP 7.5-10 HP
Input Voltage 500 VAC
Hz 50/60Hz
Labeling UL Listed, IEC Certified

About the 2DF4284

The 2DF4284 module was created and manufactured by Reliance Electric as part of the SP500 series. The 2DF4284 module is classified as a Mains Filter.

A Mains Filter, such as the 2DF4284 module, is designed to be housed inside of a compact NEMA 1 (IP21) enclosure. The Mains Filter is designed to be mounted between a wall or a back panel and the SP500 itself. To accomplish this, a Mains Filter is outfitted with tapped holes and pre-drilled holes on the filter enclosure. Any incoming AC power is designed to be routed into the top of the filter. Any outgoing AC power is routed from the bottom part of the filter to the bottom part of the SP500. Provided with a Mains Filter are flying leads and mounting hardware.

The 2DF4284 Mains Filter is rated for 3-phase, 50/60 Hz, 500 VAC maximum. The 2DF4284 can perform at either 7.5 HP or 10HP, depending on the user’s needs. The 2DF4284 Mains Filter is small in size. It is a metal device with four wires coming out of the top: One red, one green, one yellow, and one blue.

The entire 2DF4284 Mains Filter weighs about 10.00 lbs. or 4.54 kg. This total does not include any of the materials that AX Control uses in the packaging. We take pride in our shipping materials, which are made to withstand any bump or fall that may occur during the shipping and handling process. Learn more about our shipping information by following the link here.
