S12-403P8LU by Reliance Electric 2HP 390-480V AC Drive

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-403P8LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-403P8LU

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
S12-403P8LU by Reliance Electric 2HP 390-480V AC Drive

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-403P8LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-403P8LU Technical Specifications

Enclosure Protected Chassis (IP 20)
HP 2 HP
Hz 50/60Hz
Input Voltage 390-480 VAC
Keypad/Display Keypad
kW 1.5kW
Labeling UL Listed, IEC Certified
Manufacturer Reliance Electric
Part Number S12-403P8LU
Series SP120

Product Description

S12-403P8LU is an AC SP120 drive that is manufactured by Reliance Electric. The voltage rating is 460 VAC for this three-phase drive. The enclosure type is a protected IP20 chassis. This drive includes a keypad. The output current is 3.8 A. The horsepower is 2.0 HP (1.5 kW) at 460 V.

There are a number of adjustable parameters on the drive. The Automatic Start After a Fault parameters include the Restart Mode Select, the Power Loss Time, and the Restart Time. The range of b01 (Restart Mode Select) is 00 to 03, and the factory default is 00. The range of b02 (Power Loss Time) is 0.3 to 25.0 seconds, and the factory default is 1.0 second. The range of b03 (Restart Time) is 0.3 to 100.0 seconds, and the factory default is 1.0 second. The Electronic Motor Protection parameters include the Motor Overload Current and the Motor Overload Select. The range of b12 (Motor Overload Current) is 5 to 120% of the rated current amps, and the factory default is 115% of the drive rating. The range of b13 (Motor Overload Select) is 00 to 01, and the factory default is 01.

The Current Limit parameters include the Current Limit Select, the Current Limit, and the Current Limit Decel Time. The range of b21 (Current Limit Select) is 00 to 02, and the factory default is 01. The range of b22 (Current Limit) is 50 to 150% of the rated current amps, and the factory default is 150% of the drive rating. The range of b23 (Current Limit Decel Time) is 0.3 to 30.0 seconds, and the factory default is 1.0 second.

Frequently Asked Questions about S12-403P8LU

What are some of the standard features of the SP120 drives?
The SP120 drives come standard with integral local keypad for adjustment, 5 parameter groups, screw control terminals provide reliable connections, small adjustment set, and diagnostic parameters to easily track faults.
What are the SP120 drives control selection?
The four control selections are single-channel analog input,speed potentiometer, preset speeds, and PID (proportional–integral–derivative).
