S12-402P5LU Reliance Electric 1HP SP120 AC Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-402P5LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-402P5LU

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
S12-402P5LU Reliance Electric 1HP SP120 AC Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-402P5LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-402P5LU Technical Specifications

Enclosure Protected Chassis (IP 20)
HP 1 HP
Hz 50/60Hz
Input Voltage 460 VAC
Keypad/Display Keypad
kW 0.75kW
Labeling UL Listed, IEC Certified
Manufacturer Reliance Electric
Part Number S12-402P5LU
Series SP120

Product Description

Reliance Electric is the maker of S12-402P5LU, an AC drive from the SP120 series. The voltage rating is 460 VAC for this three-phase drive. The enclosure type is a protected IP20 chassis. This drive includes a keypad. The output current is 2.5 A. The horsepower is 1.0 HP (0.75 kW) at 460 V.

There are a number of adjustable parameters on the drive. The Automatic Voltage Regulation parameters include the AVR Function Select and the Base Voltage. The range of A81 (AVR Function Select) is 00 to 02, and the factory default is 02. The range of A82 (Base Voltage) is 200 to 460 volts, and the factory default is 230 volts or 460 volts.

The Second Acceleration/Deceleration Ramp parameters include Accel Time 2, Decel Time 2, Accel/Decel 2 Select, Accel 2 Start Frequency, Decel 2 Start Frequency, the Accel Curve, and the Decel Curve. The range of A92 (Accel Time 2) is 0.1 to 3000 seconds, and the factory default is 15.0 seconds. The range of A93 (Decel Time 2) is 0.1 to 3000 seconds, and the factory default is 15.0 seconds. The range of A94 (Accel/Decel 2 Select) is 00 to 01, and the factory default is 00. The range of A95 (Accel 2 Start Frequency) is 0.0 to 360.0 Hz, and the factory default is 30.0 Hz. The range of A96 (Decel 2 Start Frequency) is 0.0 to 360.0 Hz, and the factory default is 30.0 Hz. The range of A97 (Accel Curve) is 00 to 01, and the factory default is 00. The range of A98 (Decel Curve) is 00 to 01, and the factory default is 00.

Frequently Asked Questions about S12-402P5LU

How many different control modes are built into this drive?
There are 4 different control modes that are built into all models of SP120 drives to make it easy to control.
What are the 5 groups of programming and their meanings?
The 5 parameter groups that help simplify programming are the A group that are control parameters, B group is the protection parameters, and the C group helps I/O setup parameters. D group that helps display & diagnostic parameters, F group helps basic function parameters.
