S12-202P6LU Reliance Electric .5HP 200-240VAC AC Drive

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-202P6LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-202P6LU

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
S12-202P6LU Reliance Electric .5HP 200-240VAC AC Drive

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a S12-202P6LU to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

S12-202P6LU Technical Specifications

Enclosure Protected Chassis (IP 20)
HP 0.5 HP
Hz 50/60Hz
Input Voltage 200-240 VAC
Keypad/Display Keypad
kW 0.4kW
Labeling UL Listed, IEC Certified
Manufacturer Reliance Electric
Part Number S12-202P6LU
Series SP120

Product Description

S12-202P6LU is manufactured by Reliance Electric for the AC SP120 drive series. The voltage rating is 230 VAC for this drive. This drive does not have an IP20 enclosure, but it does include a keypad. The output current is 2.6 A. The horsepower is 0.5 HP (0.4 kW) at 230 V.

Inside of a cabinet, the SP120 drive should be mounted 100 mm from the top and bottom of the cabinet and 30 mm from the sides of the cabinet. This allows for proper circulation of air through the heat sink. The drive comes with pre-installed electronic overload protection for the motor. The drive also has a high leakage current and must be permanently hard wired to ground. Ground each drive separately if multiple drives are used. The user must also wire the control terminal block by running all signal wiring in either a separate metal conduit or a shielded cable. When wiring the alarm relay, use 0.75 mm2 (18 AWG) wire. When wiring all other signal connections, use 18 AWG to 28 AWG (0.75 to 0.14 mm2), twisted pair, shielded, or 3 conductor wire. Do not cross motor lines or power lines with the control wires. If they must cross, ensure that they cross at 90° angles. To prevent damage to the output when using transistor outputs 11 or 12 with an inductive load such as a relay, install a recovery diode parallel to the relay. Control wiring cannot be longer than 20 meters.

Frequently Asked Questions about S12-202P6LU

How should this drive be mounted?
This S12-202P6LU drive should be mounted on a flat, vertical, and level surface. For proper dissipation of heat the drive must be mounted vertically with the top up right.
What are the input power conditions?
Within the rated voltage of the drive, is it suitable for connection to an input power. The power factor should not exceed .99 of the input power supply.
Is there a manual for this Reliance Electric drive?
Yes and we would be happy to send a link via email. Please send a request to our email sales@axcontrol.com and we will send a link to the manual for this Reliance Electric drive.
