Reliance Electric 45C993 2-Point Analog Output Module for Shark XL

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 45C993 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C993
  • SKU: 45C993RE
  • Manufacturer: Reliance Electric
  • Series: Shark XL

45C993 Technical Specifications

Manufacturer Reliance Electric
Series Shark XL
Part Number 45C993

About the 45C993

The 45C993 device is an analog output module that Reliance Electric created to be a part of the Shark XL series. The 45C993 analog output module will usually be in stock at AX Control even though the Shark XL series is now a legacy series and therefore not in production. The availability of the 45C993 analog output module will be displayed on the product’s page on our website.

The 45C993 analog output module is very related to the 45C995 analog output module. There are only slight differences between these two analog output modules, mainly in the number of channels and the current consumption rating for one of the channels. In the event that you would like to order the 45C995 analog output module or simply learn more about it, follow the link above to find it on our website.

The 45C993 analog output module has two total channels with a current that can be anywhere in the range of 4 to 20 mA. The load impedance for this module is at a range of 0 through 500 Ohms. In addition, the conversion time is only one millisecond. The 45C993 analog output module also has an 8-bit resolution and an overall accuracy of +/- 1%. For this product, isolation between the outputs is not provided and there is no isolation from the DC inputs. Lastly, the average current consumption for the 45C993 analog output module varies based on which channel is being observed. Channel 1 is 50 mA, Channel 2 is 0 mA, and Channel 3 is 140 mA.

Frequently Asked Questions about 45C993

How many channels does the 45C993 have?
The 45C993 is a 2-channel analog output module. There is one other 2-channel analog output module besides 45C993 in the Shark XL series.
What is the output on the 45C993?
The 45C993 has an output of 4-20 mA.
Where should the 45C993 be installed?
The 45C993 is an output module which should be kept in a Shark XL rack. The racks are designed to hold input/output modules and a power supply module.
Where can I find the manual for the 45C993?
You can find the Shark XL Series manual by searching the manual number J-3809-2 online or contact AX Control. The Shark XL manual provides detailed information on the45C993.
