Reliance Electric Shark XL Relay Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C966 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C966

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric Shark XL Relay Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C966 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C966 Technical Specifications

Manufacturer Reliance Electric
Part Number 45C966
Series Shark XL

Product Description

The 45C966 module is a relay output module that was mass-produced for the Shark XL line of products by the company known as Reliance Electric. The Shark XL product line is now considered a legacy series; however, AX Control still typically stocks many of this series’ products, and this includes the 45C966 relay output module. To verify that the 45C966 relay output module is currently inside of our stock, then use our website or contact us during our hours.

The 45C966 relay output module has many similarities with two other Shark XL relay output modules. These other relay output modules are the 45C967 and the 45C959. The main similarities between these three relay output modules lie mainly in their specifications, such as the voltage and current ratings. There are, however, some differences amongst these three modules that are worth considering when you are choosing the right product for your facility. To learn more about these other two relay output modules, click on their links above to go to their assigned places on our website.

The 45C966 relay output module possesses the output voltage range of 21 VDC through 27 VDC and 85 VAC through 264 VAC. The nominal voltage is 115 VAC/230 VAC and 24 VDC. The maximum load current for the 45C966 relay output module is dependent on the amount of circuits. With one circuit, the maximum load current is 2 A and at eight circuits, the maximum load current is doubled to 4 A. The maximum inrush current for the 45C966 relay output module is set to 6 A for 100 milliseconds.

Frequently Asked Questions about 45C966

What exactly is a 45C966?
The 45C966 is a Reliance Electric Shark XL 8-channel relay output digital ouput module.
What does the 45C966 have for connecting external output devices?
The 45C966 has LED status indicators and terminals for connecting external output devices to the programmable logic controller.
Does AX Control offer a warranty with the 45C966?
Yes, AX Control provides a three year warranty when you purchase any PLC incluing the 45C966. If your 45C966 stops functioning within the three years we will provide you with a new device, grant you a full refund, or fix and repairs.
How should the 45C966 be installed?
The 45C966 should be placed inside a Shark XL rack. The Shark XL racks can hold multiple input/output modules and power supply modules.
