Reliance Electric 45C963 Shark XL Transistor Output Module



Sell Surplus: Have a 45C963 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C963
  • SKU: 45C963RE
  • Manufacturer: Reliance Electric
  • Series: Shark XL

45C963 Technical Specifications

Manufacturer Reliance Electric
Series Shark XL
Part Number 45C963
Output Voltage 57 VDC

Product Description

The 45C963 device is a 5-27 VDC output module which was made by Reliance Electric to be included in the Shark XL product family. The 45C963 output module is no longer being made by Reliance Electric; however, AX Control may have this product in stock despite that. If you would like to check on the 45C963 output module’s current availability in our stock, our website helpfully displays this information on its page.

There are two other 5-27 VDC output modules other than the 45C963 output module. All three of these modules are all very similar in its specifications, although there are slight differences between them. These other two output modules possess the following module numbers: 45C962 and 45C964. Please click on these links if you would like to learn more about these products and figure out which one is the best option for your facility.

The 45C963 output module has sixteen channels that are available for use. The output voltage is at a range of 5 through 27 VDC and the nominal voltage for this module is 24 VDC. This product uses common terminal polarity and the opto-isolator isolation method. The maximum current for leakage for this product is only 0.1 mA while the maximum current at inrush is 3 A. There are two commons on this device, for a total of eight output points per common terminal. For each common, there is a single fuse for a total of two fuses for the whole module, which are SOC fuses that are rated at 250 V and 8 A.

Frequently Asked Questions about 45C963

What exactly is a Reliance 45C963?
The 45C963 is a 16-channel, 5-27 VDC output digital output module. The 45C963 is one of eleven Reliance Electric Shark XL digital output modules.
How many terminals does the 45C963 have?
The 45C963 has 15 total terminals. Terminals 0-7 on the 45C963 are the common C1 terminals and terminals 8-15 on the 45C963 are common C2 terminals.
Where should the 45C963 be stored?
The 45C963 is an output module that should be stored in a Shark XL rack. The Reliance rack can hold mulltiple input/output modules and a power supply module.
Where can I find the 45C963's manual?
The 45C963 is included in the Reliance Electric Shark XL manual which discusses the PLC as a whole as well as details about each specific device. Please contact AX Control if you need the Shark XL manual.

Repair Services For 45C963

Type Lead Time Price Action
Repair Service 1-2 weeks $683

Our highly skilled technicians can repair your 45C963. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
