Reliance Electric 45C960 8-Point 115/230 VAC Shark XL Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C960 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C960

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric 45C960 8-Point 115/230 VAC Shark XL Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C960 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C960 Technical Specifications

Manufacturer Reliance Electric
Output Voltage 115/230 VAC
Part Number 45C960
Series Shark XL

Product Description

The 45C960 model is a digital output module that was designed for the Shark XL programmable controller series by Reliance Electric. Although Reliance Electric is not making the 45C960 digital output module anymore, AX Control may have it in stock. You can check the availability of the 45C960 digital output module in our inventory by looking on our website, as it is designed in such a way where the availability of our products will be displayed prominently on its specific page.

The 45C960 digital output module two other modules that are very similar to it. These products have the model numbers 45C961 and 45C965. Most of the specifications of these three products are exactly the same aside from the amount of channels that they have and other details. To learn more about the differences between these modules, click on the links above so you can compare and contrast them.

The 45C960 digital output module has an output voltage rating that ranges from 85 VAC to 264 VAC and a nominal voltage rating of either 115 VAC or 230 VAC. This device has eight output points with one common terminal and one fuse for the common. This fuse is an SOC fuse, which is rated at 8 A, 250 V, MQ4. The output delay time for this module at its very highest for both ON to OFF and OFF to ON will be 11 milliseconds. The maximum leakage current is 1 mA/100 VAC and the maximum inrush current is 20 A. This product is UL listed.



Frequently Asked Questions about 45C960

What the purpose of the 45C960?
The 45C960 is a digital output module used to connect ouput devices to the Shark XL PLC. The 45C960 is one of eleven Shark XL digital output modules.
What is the output current on a Reliance 45C960?
The output current on a Reliance Shark XL 45C960 is 115/230 VAC.
Where can I find the manual for the 45C960?
The 45C960 does not have a specific manual but is included in the Reliance Shark XL manual. You can contact AX Control for the manual or search the manual number J-3806-2 online.
How should the 45C960 be installed?
The 45C960 should be placed inside a Shark XL rack which can be installed on a flat mounting surface.
