Reliance Electric 45C910 Shark XL 3-Slot Rack

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C910 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C910

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric 45C910 Shark XL 3-Slot Rack

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C910 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C910 Technical Specifications

Manufacturer Reliance Electric
Part Number 45C910
Series Shark XL

Product Description

The 45C910 module is a rack that the company Reliance Electric is responsible for contributing to the market. The 45C910 rack was made for the Shark XL series, which was also created by Reliance Electric. This particular rack can typically be found within our stock here at AX Control, but you can check its availability in our stock by looking it up on our website or by contacting one of the staff members on our team of professionals.

The 45C910 rack is classified as a three-slot rack even though it has a total of four slots. One of these slots is used for a Shark XL power module. The other three slots are used for Shark XL processor and I/O modules.

The inside of the 45C910 rack is comprised of only a few components. There are backplane connectors equivalent to the amount of slots with which the rack is outfitted. There are also two small mounting holes at the top of the 45C910 rack to facilitate installation. On the side of the 45C910 rack, and all of the other Shark XL racks, you will be able to find an expansion rack connector piece. By using the piece, you will be granted the ability to connect the 45C910 rack with other Shark XL racks to expand the amount of Shark XL modules that you can hold at any given time.

When you are mounting the 45C910 rack, be sure to not mount the rack in any place where it will be exposed to direct sunlight or where a heat source will be located below it. Also, there should be at least eight inches between the rack and any lines that are over 3000 V and plenty of space away from any sources of excessive shock or vibration.

Frequently Asked Questions about 45C910

What is the function of the 45C910?
The 45C910 is rack used to hold power modules, input/output modules, and other Shark XL devices. The Shark XL PLC has a rack design which enables it to be compat and flexible.
How many racks is the 45C910 equipped with?
The 45C910 is a three slot rack. The 45C910 has a slot for the power module and then three additional slots for I/O modules.
Where is the expansion rack connector located on the 45C910?
The expansion rack connector is located on the side of the 45C910. You can connect expansion racks for additional slots via the expansion rack connector.
Can AX Control troubleshoot my 45C910?
Yes, AX Control has the ability to troubleshoot your 45C910 and figure out the issue at hand. Once the issue is located we can compelte repairs to get your device working again.

Repair Services For 45C910

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your 45C910. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

45C910 Manuals, White Papers, Data Sheets, and Troubleshooting
