Reliance Electric 86475-10S Assembly Stack Rectifier
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 86475-10S to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 86475-10S
  • SKU: RE-9757
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

86475-10S Technical Specifications

Manufacturer Reliance Electric
Series Rectifiers & Misc.
Part Number 86475-10S

About the 86475-10S

  • The 86475-10S is a Rectifier Assembly manufactured by Reliance Electric.
  • It is used within Reliance Electric drive systems.
  • It may also be marketed under the names Baldor-Reliance and Asea Brown Boveri (ABB).
Design and Components
  • The 86475-10S is designed with a box capacitor.
  • It features a small circuit board with only a few components:
    • Two resistors.
    • Diodes.
    • Header connectors.
  • These components are mounted on top of two large heat sink towers.
  • Additional components, such as MOVs (metal oxide varistors), are mounted between the two heat sinks.
  • Wires connect these components to the circuit board or the capacitor.
  • The heat sinks are bolted together with an air gap between them.
  • One heat sink has a flat edge, while the other has a curved flange with two factory-made drill holes for mounting.
Documentation
  • For additional information, consult technical support products from Reliance Electric, including data sheets, product manuals, or series user guides.
