Rectifier Stack

AVAILABILITY:

IN STOCK
SHIPS TODAY

Warranty: Learn More
Sell Surplus: Have a 86474-8S to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 86474-8S
  • SKU: 864748SRE
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

86474-8S

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Rectifier Stack

AVAILABILITY:

IN STOCK
SHIPS TODAY

Warranty: Learn More
Sell Surplus: Have a 86474-8S to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 86474-8S
  • SKU: 864748SRE
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

Product Description

86474-8S Rectifier Stack

The 86474-8S is a Rectifier Stack assembly used within various Reliance Electric drive systems.  This component is sometimes sold under the manufacturing names of ABB or Baldor-Reliance.

The 86474-8S is designed as two large heat sink assemblies connected together by two bolts.  These “stacks”  have an extending flange on one bottom edge with two drill holes that allow the unit to be mounted into place and a flat edge on the other side.

The two heat sink stacks that make up the 86474-8S are both populated on their top surfaces with components.  One stack has a single Sprague box capacitor that has red and white braided wires connected to its two poles, while the other side is topped by a small circuit board (0-51378-15.)  This board is screw mounted to the top of the stack.  Components on its surface include a transformer, two male header pin connectors, a resistor, and a diode.  Additional red and white braided wires are attached to this card.   More components are located between the two heat sink stacks.

For more information regarding the 86474-8S, its use or installation, please refer to technical support publications originally provided by Reliance Electric.  This includes data sheets, user guides, and product manuals.

AX Control is located in North Carolina, south of Raleigh.  We maintain a warehouse of ready-to-ship parts from manufacturers like GE, Fuji, Parker, and Eurotherm, as well as many others.   Let us know what we can send to you today.

Repair Services For 86474-8S
