604580-1R Air Flow Sensing Switch

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 604580-1R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 604580-1R
  • SKU: RE-10289
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

604580-1R Technical Specifications

Manufacturer Reliance Electric
Part Number 604580-1R
Series Rectifiers & Misc.
Connections 9 Connector Pins
Electrical Rating 115 VAC
Air Flow Speed Rating 250 linear fpm
Shipping Weight 1 lb

About the 604580-1R

This switch may have also been sold by Baldor Reliance and Asea Brown Boveri when it was in production. This device has been since taken from active stock by all three manufacturers. AX Control does attempt to keep this switch in stock. Please contact us directly to check for the availability and condition of this part.


Relevant 604580-1R Hardware Inclusions

Product Type: Air Flow Sensing Switch.

  • Manufacturer: Reliance Electric.
  • Model Number: 604580-1R.
  • Compatibility: Designed for use with MaxPak Plus DC variable speed drive systems. Only one switch is needed per drive.
  • Electrical Rating: 115 VAC.
  • Connections: Features 9 connector pins.
  • Contact Configuration: Normally Closed (NC).
  • Air Flow Speed Rating: 250 linear feet per minute.
  • Operating Principle:
    • Senses temperature changes to detect airflow.
    • A rise in temperature indicates a reduction in airflow.
    • Upon detection of reduced airflow below a certain level, it signals to shut down the device.
    • Automatically resets when normal airflow levels are restored (sensor cools down).
  • Documentation: Refer to Reliance Electric datasheets, specifically D-3919-1, for installation details. AX Control can assist in locating these documents if lost during purchase.

Reviews For 604580-1R

Internal Review
(5.0)

The Reliance Electric 604580-1R Air Flow Sensing Switch is vital for MaxPak Plus DC drive systems, ensuring proper thermal management. Though discontinued, its role in equipment longevity remains critical. This switch intelligently senses airflow via temperature changes. If airflow drops below 250 linear feet per minute, its temperature rises, triggering a shutdown signal to prevent overheating. It then automatically resets once normal airflow resumes, acting as a reliable, self-sufficient safety device. Electrically, it's a 115 VAC, 9-pin, Normally Closed (NC) unit, requiring only one per drive for straightforward installation. Despite its obsolete status, the 604580-1R is an essential component for MaxPak Plus system maintenance. Consult Reliance Electric datasheets (like D-3919-1) for installation, and remember that specialized suppliers can often help with availability and documentation. - AX Control Technician

Repair Services For 604580-1R

Type Lead Time Price Action
Repair Service 1-2 weeks $673

Our highly skilled technicians can repair your 604580-1R. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
