11C81K 2-3HP Dynamic Brake Kit
The 11C81K is a Dynamic Brake Kit with Contactor that was sold by Reliance Electric as a replacement part/kit part for their drive systems. It is rated 2-3 HP. Reliance parts were sometimes sold under the alternate company names of Baldor-Reliance or Asea Brown Boveri. Dynamic braking kits allow the motor to come to a rapid and smooth stop rather than coasting to a rest.
The 11C81K is a long, narrow circuit board populated with only a few board components. One of these is a ten-position terminal strip. Each of the screw connections on the terminal strip has a numerical label. It can accept a cover. The board has a transistor, a polyester vinyl capacitor, wire wound and carbon composite resistors, and diodes. The board has a contactor with multiple screw mounts and several surface wires. These wires use several different types of ends, including female stab-on connector covers and terminal loops.
For more information please consult technical support publications like user guides, product manuals, and data sheets. Technical support products were provided to users with their OEM purchases. We will be happy to help source replacements for lost or misplaced support paperwork.
