Reliance Electric 6MDVN-5P0102 1HP 120 VAC MD-65 Motor Controller

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 6MDVN-5P0102 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6MDVN-5P0102
  • SKU: 6MDVN5P0102RE
  • Manufacturer: Reliance Electric
  • Series: MD65 Drives

6MDVN-5P0102 Technical Specifications

Manufacturer Reliance Electric
Series MD65
Part Number 6MDVN-5P0102
HP 1HP
Input Voltage 120 VAC
Hz 50/60Hz
kW 0.75kW

About the 6MDVN-5P0102

The 6MDVN-5P0102 is a Reliance Electric 1 HP MD65 AC Drive. It may have also been sold by ABB, Baldor Reliance, and Rockwell Automation at one point, but it is no longer receiving any support from these companies anymore. The 6MDVN-5P0102 may be a little tricky to find, but AX Control still attempts to keep this drive in stock. Please contact us directly for its availability, pricing, and shipping choices.

The 6MDVN-5P0102 is 120 VAC 50/60 Hz and single-phase. It is 0.75 kW and has an output current of 5 amps. It is 3.94” wide, 7.09” tall, and 5.35” thick. It weighs right around 4.9 lbs. It has an RS-485 serial connection that can interface with a PC.

The 6MDVN-5P0102 has a keypad and 4-character LED display. There are three LED indicators on either side of the display that indicate the drive status. The LEDs on the left side are labeled Run, FWD, and REV. The LEDs on the right are labeled Volts, Amps, and Hertz. There are two LEDs below the display that are labeled Fault and Program. There are two arrow up/down keys, a program key, an enter key, a reset key, a green start key with a corresponding LED, and a red stop key. There is also a max/min dial with a matching LED. Under the keypad and display is a panel that can be removed to reveal three I/O terminal strips and the RS-485 connection. There is also an enable jumper, an analog output select switch and a SNK/SRC switch.

Frequently Asked Questions about 6MDVN-5P0102

What are some features the 6MDVN-5P0102 is equipped with?
The 6MDVN-5P0102 comes equipped with a variety of special features including an auto restart, four logi digital input points, and DC braking abilities.
How many programmable preset speeds does the 6MDVN-5P0102 have?
The 6MDVN-5P0102 comes with eight programmable preset speeds.
What is the output voltage of the 6MDVN-5P0102?
The 6MDVN-5P0102 has a input voltage of 120 VAC with an output voltage of 5.0A.
