Reliance Electric D2-3519-2 3HP 480 VAC Brushless Servo MD-65 Motor Controller

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 6MDDN-6P0102 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6MDDN-6P0102
  • SKU: 6MDDN6P0102RE
  • Manufacturer: Reliance Electric
  • Series: MD65 Drives

6MDDN-6P0102 Technical Specifications

Manufacturer Reliance Electric
Series MD65
Part Number 6MDDN-6P0102
HP 3HP
Input Voltage 480 VAC
Hz 50/60Hz
kW 2.2kW

About the 6MDDN-6P0102

The 6MDDN-6P0102 is a 3HP Reliance Electric MD65 AC Drive. This drive may have also been sold under the ABB or Baldor Reliance product lines at some point, but it is no longer receiving any type of support form any of these original companies. It might be a little hard to locate now, but AX Control tries to keep it in stock.

The 6MDDN-6P0102 is a sensorless vector control microdrive. This drive is 380/480 VAC, 3-phase, and 50/60 Hz. It is 2.2 kilowatts and has an output current of 6 amps. This drive comes in a standard frame that is 100 mm wide x 180 mm tall x 136 mm deep. It is roughly 2.2 kg. It comes with many protective features that include a power loss ride-through of 500 msec, an over-temperature heatsink monitor, and a drive overload function that can allow a user to go beyond the drive rating up to 150% for one minute. This drive also comes with some basic performance features that include but are not limited to an adjustable current limit, eight programmable preset speeds, an auto restart, a three-deep memory, and a one band frequency avoidance. It has one analog output and four digital inputs.

The 6MDDN-6P0102 is a small rectangular box. It has air vents on its top and sides that helps air to flow to the internal circuitry of the drive. The faceplate on the drive has a 4-character LED display. It also has six LED indicators that are dedicated to the display that will indicate the drive’s status. Below the displays are a program and fault LED and four keys that are used to scroll through the display. There is also a min/max knob with an LED, a power button, a stop button, and a reset button.

Frequently Asked Questions about 6MDDN-6P0102

What type of display does the 6MDDN-6P0102 have?
The 6MDDN-6P0102 comes equipped with a four-character LED digital display.
What type of enclosures are compatible with the 6MDDN-6P0102?
The 6MDDN-6P0102 is compatible with a NEMA 1 or open chassis enclosure that helps protect the drive from becoming damaged.
Where can I find the manual for the 6MDDN-6P0102?
The 6MDDN-6P0102 is included in the MD-65 Series drive manual. The manual D2-3519-2 has detailed information on the drive series and models.
How should the D2-3519-2 be installed?
The D2-3519-2 should be installed in a vertical postition on a flat surface. The D2-3519-2 should be place in an environment that has little moisture and dust in the air.
