Reliance Electric 6MDBN-8P0102 50/60Hz 240 VAC MD-65 Motor Controller

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 6MDBN-8P0102 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6MDBN-8P0102
  • SKU: 6MDBN8P0102RE
  • Manufacturer: Reliance Electric
  • Series: MD65 Drives

6MDBN-8P0102 Technical Specifications

Manufacturer Reliance Electric
Series MD65
Part Number 6MDBN-8P0102
HP 2HP
Input Voltage 240 VAC
Hz 50-60Hz
kW 1.5kW

Product Description

The 6MDBN-8P0102 is a 2 HP MD65 Reliance Electric AC Drive. This drive could have been also mass-produced by Baldor Reliance and/or ABB, but support for it has since been suspended. It may be a little hard to find, but AX Control still tries to keep it stocked.

The 6MDBN-8P0102 is a sensorless vector control microdrive. It is 240 VAC, 50/60 Hz, and 3-phase. It is 1.5 kW and has an output current of 8 amps. It is 100 mm wide, 180 mm tall, and 136 mm thick. It weighs roughly 2.2 kg. This drive has a three deep fault memory and an auto-restart function. It has four logic digital inputs and one analog input that is 4-20 mA. It has a total of eight programmable preset speeds. It also can adjust the current limit for the motor by 10% to 150%. It can be operated in temperatures ranging from -10 to +50 degrees Celsius.

The 6MDBN-8P0102 is a small rectangular box. It has a faceplate with several key features. It has a 4-character LED display with a series of 6 LED indicators surrounding it. These LEDs are labeled Run, FWD, REV, Volts, Amps, and Hertz. There are two other indicators that are directly below the display that are labeled Program and Fault. Below that are four keys that are labeled PROG, enter, and two up/down arrow keys. Below that is a min/max dial with a dedicated LED, a green power button with an LED, a reset button, and a stop button.

Frequently Asked Questions about 6MDBN-8P0102

What is the function of the 6MDBN-8P0102?
The 6MDBN-8P0102 is a micro drive within the Reliance MD-65 Series. The 6MDBN-8P0102 can be used to control and power other Reliance motors.
What motors are compatible with the 6MDBN-8P0102?
The 6MDBN-8P0102 is compatible with both Reliance S-Series and F-Series motors.
Does AX Control offer a warranty with the 6MDBN-8P0102?
Yes, AX Control offers a two year warranty with all drives we sell including the 6MDBN-8P0102. If your 6MDBN-8P0102 stops working please contact us and we will send you a new drive, complete any repairs, or grant you a full refund.
What is the 6MDBN-8P0102's output voltage?
The 6MDBN-8P0102 has an input voltage of 240 VAC and an output voltage of 8.0A.

Repair Services For 6MDBN-8P0102

Type Lead Time Price Action
Repair Service 1-2 weeks $401

Our highly skilled technicians can repair your 6MDBN-8P0102. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
