Reliance Electric 6MDBN-2P3102 240 VAC o.4 kW Phase 1 MD-65 Series Drive

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 6MDBN-2P3102 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6MDBN-2P3102
  • SKU: 6MDBN2P3102RE
  • Manufacturer: Reliance Electric
  • Series: MD65 Drives

6MDBN-2P3102 Technical Specifications

Manufacturer Reliance Electric
Series MD65
Part Number 6MDBN-2P3102
HP 0.5 HP
Input Voltage 240 VAC
Enclosure NEMA 1 or Chassis
Hz 48-63Hz
kW 0.4kW
Filter/No Filter Not Filtered
Labeling UL Listed, IEC Certified

About the 6MDBN-2P3102

6MDBN-2P3102 is a 200-240 VAC 3-phase input, 0-230 V 3-phase output MD65 drive that is manufactured by Reliance Electric. The user may need to troubleshoot faults on the drive. These faults are indicated by fault codes that begin with F. F38-F40 are the phase to ground fault, which means that there is a fault between the motor and the drive. To correct this fault, check for a grounded phase on the motor and check the motor and the drive wiring. If the fault cannot be cleared, the user must replace the drive. The phases that may fault in this case are U, V, and W. F41-F43 are the phase to phase shorts, which means that an excessive current has been detected between two output terminals. To correct this fault, check for a shorted condition on the motor and drive output terminal. If the fault cannot be cleared, the user must replace the drive. F48 is the params defaulted fault, which means that the drive was commanded to write default values to EEPROM. To correct this fault, cycle power to the drive and program the drive parameters as needed. F63 is the SW OverCurrent fault, which means that the programmed SW Current Trip (A098) has been exceeded. To correct this fault, check the load requirements and the SW Current Trip (A098) setting. F64 is the drive overload fault, which means that the drive rating was 150% for 1 minute or 200% for 3 seconds. To correct this fault, extend the acceleration time or reduce the drive load.

Frequently Asked Questions about 6MDBN-2P3102

What enclosures are available with the 6MDBN-2P3102?
The 6MDBN-2P3102 is compatible with both a NEMA 1 and an open chassis enclosure that protects it from becoming damaged.
What are some of the 6MDBN-2P3102's features?
The 6MDBN-2P3102 has a variety of features including programmable preset speeds, analog inputs, and adjustable current limit.
Is the MD-65 Series similar to the MD-60 Series?
Yes, the MD-65 Series is very similar to the MD-60 Series. The MD-65 are both high performance sensorless vetor drives but the MD-65 Drives are mircodrives.
Does AX Control provide a warranty with the 6MDBN-2P3102?
Yes, AX Control provides a two year warranty with the 6MDBN-2P3102. If your 6MDBN-2P3102 stops functioning we will send you a new drive, complete all repairs, or grant you a full refund.

Repair Services For 6MDBN-2P3102

Type Lead Time Price Action
Repair Service 1-2 weeks $495

Our highly skilled technicians can repair your 6MDBN-2P3102. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
