Reliance Electric 6MDBN- 033102 50/60Hz 7.5kW Phase 1 MD-65 Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 6MDBN-033102 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

6MDBN-033102

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
Reliance Electric 6MDBN- 033102 50/60Hz 7.5kW Phase 1 MD-65 Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 6MDBN-033102 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

6MDBN-033102 Technical Specifications

HP 10HP
Hz 50/60Hz
Input Voltage 240 VAC
kW 7.5kW
Manufacturer Reliance Electric
Part Number 6MDBN- 033102
Series MD-65

Product Description

6MDBN-033102 is a 200-240 VAC 3-phase input, 0-230 V 3-phase output MD65 drive that is manufactured by Reliance Electric. The user can troubleshoot the drive with fault codes. F6 is the motor stalled fault, which means that the drive is unable to accelerate the motor. To correct this fault, either reduce the load or increase the acceleration time. F7 is the motor overload fault, which means that there is an internal electronic overload trip. To correct this fault, reduce the load on the motor and verify the boost select setting. F8 is the heatsink overtemp fault, which means that the heatsink temperature has exceeded a predefined value. To correct this fault, check the fan and the heat sink fins for obstructions. F12 is the HW overcurrent fault, which means that the drive output current has exceeded to hardware current limit. To correct this fault, check the drive programming and check for excess load on the motor. F13 is the ground fault, which means that a current path to earth ground has been detected at one or more of the drive output terminals. To correct this fault, check for a grounded condition in the motor and the external wiring to the drive output terminals. F29 is the analog input loss fault, which means that a signal loss has occurred. To correct this fault, check for broken or loose connections at the inputs, and check the parameters. F33 is the auto restart tries fault, which means that the drive attempted to restart a fault and was unsuccessful. To correct this fault, manually clear the original fault.

Frequently Asked Questions about 6MDBN-033102

What are some features the 6MDBN- 033102 comes equipped with?
The 6MDBN- 033102 comes equipped with many features including an adjustable current limit, a LED display, and eight programmable preset speeds.
What type of protective features does the 6MDBN- 033102 have?
The 6MDBN- 033102 has multiple features used to protect itself from damages such as a ground fault, over temperature montior, and an overcurrent fault.
Can AX Control repair my 6MDBN- 033102?
Yes, AX Control technicians are trained to complete board level repairs to get your devices fully functioning again. If your 6MDBN- 033102 is not working correctly please contact us and we can complete the repairs.
What frame size does the 6MDBN- 033102 have?
The 6MDBN- 033102 has a frame size C.

Repair Services For 6MDBN-033102

Type Lead Time Price Action
Repair Service 1-2 weeks $341

Our highly skilled technicians can repair your 6MDBN-033102. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
