Reliance Electric 6MB40001 480 VAC 50/60 Hz 0.75 kW Phase 3 MD-65 Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 6MB40001 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6MB40001
  • SKU: 6MB40001RE
  • Manufacturer: Reliance Electric
  • Series: MD65 Drives

6MB40001 Technical Specifications

Manufacturer Reliance Electric
Series MD-65
Part Number 6MB40001
HP 1HP
Input Voltage 480 VAC
Hz 50/60Hz
kW 0.75kW

About the 6MB40001

Part of the Reliance Electric MD65 Drives series is model 6MB40001. This Phase 3 drive operates with 0.75 kW, 50/60 Hz, and 480 VAC. This RE model also has an adjustable current limit of 10% to 150%. The exterior of this drive is equipped with four logic digital input points. It only uses 1HP. Removing the cover on the drive is as easy as pressing and holding the tabs that can be found on either side of the product. It uses a frame size B and EMC filter. This drive should never be used in corrosive environments.

Model 6MB40001 should be kept in humidity ranges of 0% to 95%. When storing the product, make sure the ambient temperature stays between -40 and 85 degrees Celsius. Make sure to mount this drive out of direct sunlight, and in a place where it will not collect moisture. It should be mounted on a level and flat surface placed vertically.

Despite being discontinued by Reliance Electric, model 6MB40001 is available through AX Control. It can be bought, sold, or even repaired. There are options for rush repair services complete with a detailed report. Any repairs are given a three-year warranty. Purchases are also provided with warranties from AX Control.

Frequently Asked Questions about 6MB40001

How do I remove the cover on my 6MB40001?
To remove the 6MB40001's cover press and hold the tabs on either side of the drive and then pull out and up on the cover.
Does the 6MB40001 have an adjustable current limit?
The 6MB40001 comes equipped with an adjustable current limit 10%-150%.
Can AX Control repair my 6MB40001?
Yes, AX Control technicians are trained to repair all devices we sell inclduing the 6MB40001. Please concat AX Control if your 6MB40001 stops functioning and needs repaired.
How many digital input points does the 6MB40001 have?
The 6MB40001 has four logic digital input points on the exterior of the drive.

Repair Services For 6MB40001

Type Lead Time Price Action
Repair Service 1-2 weeks $494

Our highly skilled technicians can repair your 6MB40001. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
