A three-phase offering from Reliance Electrics' GV3000 legacy series, the GV3000U-AC023-AJ-DBT 3-phase drive has 15 HP, 11.2 kW, 50/60Hz, an input voltage rating of 380-460 VAC, and a built-in keypad; all housed in the drive's protective NEMA 12 enclosure.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a GV3000U-AC023-AJ-DBT to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000U-AC023-AJ-DBT
  • SKU: GV3000UAC023AJDBTRE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000U-AC023-AJ-DBT Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number GV3000U-AC023-AJ-DBT
HP 15 HP
Input Voltage 380-460 VAC
Enclosure NEMA 12
Keypad/Display Built-In Keypad
Phase 3 Phase
kW 11.2kW
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

About the GV3000U-AC023-AJ-DBT

The GV3000U-AC023-AJ-DBT-model drive from Reliance Electric is a 15 HP drive with an input voltage range of 380 to 460 VAC. the GV3000U-AC023-AJ-DBT comes equipped with a NEMA 12-type enclosure, a built-in keypad, kilo wattage of 11.2kW, and a Hz rating of 50/60Hz. A member of the discontinued GV3000 legacy drive line, this is a chassis-style drive; designed for installation in a cabinet space.

The GV3000U-AC023-AJ-DBT is a solid GV3000 series unit, but at times even the conscious owner will encounter a common fault in installation or operation of the drive. One such fault that owners of the GV3000U-AC023-AJ-DBT have experienced in the past is the High DC bus voltage fault, which is represented by the fault code HU on the drive’s interface. This fault is typically caused by a loss or initial lack of sufficient capacitor protection, or by the drive’s shortened deceleration time. If the cause of the fault is found to be an excessive DC bus voltage, the corrective action would be to check the voltage of the drive’s input line, and to add a transformer if deemed necessary. If the cause of the drive’s HU fault is determined to be a shortened deceleration time, then the true corrective action for the GV3000U-AC023-AJ-DBT drive owner would be to raise the deceleration time versus the maximum speed/Hz, and to install a DB option with resistors.

If more information is needed about the GV3000U-AC023-AJ-DBT drive, potential fault codes, or the GV3000 series from Reliance Electric, please review manual D2-3359 & D2-3360, available through our website here at AXcontrol.com

Frequently Asked Questions about GV3000U-AC023-AJ-DBT

What is the input phase loss fault code error on GV3000U-AC023-AJ-DBT?
The input phase loss fault code on GV3000U-AC023-AJ-DBT is fault "IPL." This fault on GV3000U-AC023-AJ-DBT is caused by a voltage ripple on DC bus due to missing input phase on GV3000U-AC023-AJ-DBT or an imbalance between phases on GV3000U-AC023-AJ-DBT. To correct this fault, verify that proper voltage is being applied to GV3000U-AC023-AJ-DBT. Also check all phases on GV3000U-AC023-AJ-DBT.
How do you select how GV3000U-AC023-AJ-DBT responds to high bus voltage?
To select how GV3000U-AC023-AJ-DBT responds to high bus voltage, adjust parameter U.024- the high DC bus fault avoidance enable parameter. When this parameter is turned on on GV3000U-AC023-AJ-DBT, GV3000U-AC023-AJ-DBT will attempt to regulate the DC bus on a high bus condition. This is a tunable parameter.
How much input KVA does GV3000U-AC023-AJ-DBT have?
GV3000U-AC023-AJ-DBT has 20.2 input KVA.
Where do I get the manuals for GV3000U-AC023-AJ-DBT?
We can send you the manuals for GV3000U-AC023-AJ-DBT. The manuals for GV3000U-AC023-AJ-DBT are manuals D2-3359 and D2-3360. These are the software and hardware manuals for GV3000U-AC023-AJ-DBT. Both manuals will help you in different ways with GV3000U-AC023-AJ-DBT.

Reviews For GV3000U-AC023-AJ-DBT

Internal Review
(5.0)

The GV3000U-AC023-AJ-DBT is a reliable and high-powered drive; part of Reliance Electric’s GV3000 series. The drive’s 380-460 VAC voltage is more than enough to handle the 15HP drive’s everyday use. Additionally, the GV3000U-AC023-AJ-DBT features a customizable high bus voltage response accessible through the drive’s tunable parameters.
