Home Reliance Electric GV3000 Drives GV3000U-AC023-AA-DBT

In Stock
15HP 460VAC NEMA 1 GV3000/SE | Image
2 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

GV3000U-AC023-AA-DBT

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electrics' GV3000U-AC023-AA-DBT model of 15 HP GV3000 drive comes equipped with a built-in keypad, 3 phases, a type 1 NEMA or IP20 enclosure, 50/60Hz, and 11.2kW.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a GV3000U-AC023-AA-DBT to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000U-AC023-AA-DBT
  • SKU: RE-9537
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000U-AC023-AA-DBT Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number GV3000U-AC023-AA-DBT
HP 15 HP
Input Voltage 380-460 VAC
Enclosure Type 1/IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
kW 11.2kW
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

About the GV3000U-AC023-AA-DBT

The GV3000U-AC023-AA-DBT is a drive version from the GV3000 Series. The manufacturer of this series was Reliance Electric. Although this series is now considered obsolete, or a legacy series, AX tries to keep the GV3000U-AC023-AA-DBT and other series parts in stock.

The GV3000U-AC023-AA-DBT is an AC drive with a maximum horsepower rating of 15. The GV3000U-AC023-AA-DBT has a Type 1 rated enclosure, which allows for the GV3000U-AC023-AA-DBT to be installed indoors. The GV3000U-AC023-AA-DBT has a DC-bus terminal.

Frequently Asked Questions about GV3000U-AC023-AA-DBT

How many input amps does GV3000U-AC023-AA-DBT have?
GV3000U-AC023-AA-DBT has 25.4 input amps.
What does fault code "OPL" mean on GV3000U-AC023-AA-DBT?
Fault code "OPL" is the fault error for motor output phase loss on GV3000U-AC023-AA-DBT. When this fault appears on GV3000U-AC023-AA-DBT, phase has been lost between GV3000U-AC023-AA-DBT drive and GV3000U-AC023-AA-DBT motor. To correc this fault, check connections and cable of all 3 phases and motor windings on GV3000U-AC023-AA-DBT.
Which parameter is the AC line volts parameter on GV3000U-AC023-AA-DBT?
The AC line volts parameter on GV3000U-AC023-AA-DBT is parameter U.018. This parameter identifies GV3000U-AC023-AA-DBT's phase-to-phase line voltage provided to the GV3000U-AC023-AA-DBT input power terminals. This parameter on GV3000U-AC023-AA-DBT has a parameter range of 300 to 565 VAC. The default setting for this parameter on GV3000U-AC023-AA-DBT ia 460.
What are the manuals for GV3000U-AC023-AA-DBT?
The manuals for GV3000U-AC023-AA-DBT are manuals D2-3359 and D2-3360. These manuals are the GV3000 software start-up and hardware, installation, and troubleshooting manuals for GV3000U-AC023-AA-DBT. We can send you links to either of GV3000U-AC023-AA-DBT's manuals.

Reviews For GV3000U-AC023-AA-DBT

Internal Review
(5.0)

The GV3000U-AC023-AA-DBT drive is a Reliance Electric legacy series drive, having been discontinued by its original manufacturer in 2009. In interpretation of this drive's extensive catalog number, the drive user can reveal a range of important hardware specifications. For example, the "DBT" section of the GV3000 drive's part number indicates that this model comes standard with a DC-bus terminal, and no braking unit as other similar models offer. The AC023 section of this drive's extensive catalog number reveals that the drive makes use of an AC023-type inverter PCB. More information on GV3000U-AC023-AA-DBT drive compatibilities can be found in Reliance Electrics' extensive instructional manual GV3000/SE AC General Purpose and Vector Drive Version 6.0, available online. - AX Control Lead Technician

Repair Services For GV3000U-AC023-AA-DBT

Type Lead Time Price Action
Repair Service 1-2 weeks $1189

Our highly skilled technicians can repair your GV3000U-AC023-AA-DBT. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
