Reliance Electric 5HP GV3000/SE 460V AC Drive | Image
2 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

GV3000U-AC009-AF-DBT

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric 5HP GV3000/SE 460V AC Drive
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a GV3000U-AC009-AF-DBT to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000U-AC009-AF-DBT
  • SKU: RE-9526
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000U-AC009-AF-DBT Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number GV3000U-AC009-AF-DBT
HP 5 HP
Input Voltage 380-460 VAC
Enclosure NEMA 4X/IP54
Keypad/Display Built-In Keypad
Phase 3 Phase
kW 4.0kW
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

About the GV3000U-AC009-AF-DBT

The GV3000U-AC009-AF-DBT is a GV3000 Series drive originally manufactured by Reliance Electric. The GV3000 Series is no longer manufactured, but AX does its best to keep these parts in stock.

The GV3000U-AC009-AF-DBT has a horsepower rating of 5. The input voltage for the GV3000U-AC009-AF-DBT is 380-460 VAC. The GV3000U-AC009-AF-DBT is a 3-Phase drive, which allows it to run smoothly and more efficiently. The GV3000U-AC009-AF-DBT has a built-in keypad display that allows operators to adjust parameters and settings. Fault and error codes will also show on the display.

The GV3000U-AC009-AF-DBT has a NEMA 4X enclosure rating, which allows the drive to be installed either indoors or outdoors. The enclosure protects against harsh conditions and corrosion.

Frequently Asked Questions about GV3000U-AC009-AF-DBT

What does a "UbS" fault code indicate on GV3000U-AC009-AF-DBT?
When GV3000U-AC009-AF-DBT shows fault code "UbS," it means GV3000U-AC009-AF-DBT has a bad power module. The "UbS" fault code on GV3000U-AC009-AF-DBT is the fault error for asymmetrical bus charge. To correct this fault, speak to our experts or contact Reliance about the fault error on GV3000U-AC009-AF-DBT.
What are the first menu parameters on a reliance GV3000U-AC009-AF-DBT?
GV3000U-AC009-AF-DBT has first menu general parameters P.000-P.006. Parameter P.000 on GV3000U-AC009-AF-DBT is the control source parameter. Parameter P.001 is the accel time 1 parameter on GV3000U-AC009-AF-DBT. Parameter P.002 is the decel time parameter on GV3000U-AC009-AF-DBT. Parameter P.003 is the minimum speed parameter on GV3000U-AC009-AF-DBT. Parameter P.004 is GV3000U-AC009-AF-DBT's maximum speed parameter. Parameter P.005 is the current limit parameter on GV3000U-AC009-AF-DBT. Parameter P.006 is GV3000U-AC009-AF-DBT's second menu password parameter, which brings you to second menu general parameters on GV3000U-AC009-AF-DBT.
What size wire should GV3000U-AC009-AF-DBT use?
GV3000U-AC009-AF-DBT should use a 12 AWG, 3 mm^2 size wire or lower when GV3000U-AC009-AF-DBT is wiring AC input power, output power, DC input power, or ground wiring.
What are the manuals for GV3000U-AC009-AF-DBT?
Manual D2-3359 is the software and start-up manual for GV3000U-AC009-AF-DBT. Manual D2-3360 is the hardware reference, installation, and troubleshooting manual for GV3000U-AC009-AF-DBT. Each manual is important to understanding GV3000U-AC009-AF-DBT and we are happy to send you either manual for GV3000U-AC009-AF-DBT.

Reviews For GV3000U-AC009-AF-DBT

Internal Review
(5.0)

The GV3000U-AC009-AF-DBT is an important drive for the GV3000 Series. The GV3000U-AC009-AF-DBT has a 5 HP rating and a 380-460 input voltage range. The GV3000U-AC009-AF-DBT serves operators well because it can be installed indoors and outdoors. The enclosure offers protection against the harshest elements. The GV3000U-AC009-AF-DBT has been tested to ensure full functionality. - AX Control Lead Technician

Repair Services For GV3000U-AC009-AF-DBT

Type Lead Time Price Action
Repair Service 1-2 weeks $1556

Our highly skilled technicians can repair your GV3000U-AC009-AF-DBT. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
