Frequently Asked Questions about GV3000U-AC006-AF-DBT
What are the input and output amps on GV3000U-AC006-AF-DBT?
GV3000U-AC006-AF-DBT has 6.4 input amps. GV3000U-AC006-AF-DBT has 5.3 output amps.
What are the top LEDs on GV3000U-AC006-AF-DBT's keypad display?
GV3000U-AC006-AF-DBT's keypad display first displays fault code errors or parameter values. Underneath the LEDs for fault codes and parameter values are LEDs to view multiple things on GV3000U-AC006-AF-DBT. The top two on GV3000U-AC006-AF-DBT are a "SPEED" LED and a "RUNNING" LED, which are located beside eachother directly underneath where GV3000U-AC006-AF-DBT's fault codes and paramater values are displayed. There are 14 total LEDs on GV3000U-AC006-AF-DBT's display.
Which terminals on GV3000U-AC006-AF-DBT are for RS-232 communications?
The RS-232 communications terminals on GV3000U-AC006-AF-DBT are terminals 1-3 on GV3000U-AC006-AF-DBT's terminal board. Terminal 1 on GV3000U-AC006-AF-DBT is XMIT, terminal 2 on GV3000U-AC006-AF-DBT is RECV, and terminal 3 on GV3000U-AC006-AF-DBT is the common for GV3000U-AC006-AF-DBT RS-232 communications.
Where can I find the manuals for GV3000U-AC006-AF-DBT?
We can send you links to the manuals for GV3000U-AC006-AF-DBT. The manuals are the GV3000 NEMA style software and hardware manuals, manual D2-3359 and D2-3360 and the manuals will help you greatly with GV3000U-AC006-AF-DBT. Both GV3000U-AC006-AF-DBT manuals are Reliance manuals.
